Figure 5-9 front axle - planetary drive, Front axle - planetary drive -48, See figure 5-9 for details) – SkyTrak 10042 Parts Manual User Manual
Page 220: Drive train
DRIVE TRAIN
8042/10042/10054
8990395
5-48
Figure 5-9 Front Axle - Planetary Drive
8
6
7
5
7
6
4
2
1
11
10
9
3
PH3620
8042 Before S/N 0160038967 including 0160038971 & 0160038984
10042 Before S/N 0160038368 including 0160038375, 0160038378,
0160038379, 0160038381 & 0160038383
10054 Before S/N 0160038740 excluding 0160021270, 0160036713,
0160036715, 0160036721 & 0160036723
