RECOMMENDED SPARE PARTS
The following list will service fleets of machines (built to current production per date on the front cover) with repair
parts which can be installed in the field. Parts from the list should be replaced when inventory is depleted to keep
service parts stock supplied. For further information, contact your JLG dealer or the JLG Industries Parts Department.
31200732 8042/10042/10054 12-1
SECTION 12
RECOMMENDED SPARE PARTS
Part Number Description Qty./Machine
Boom Assembly
2713452 Tilt Cylinder Hose, (8042 & 10042), (see Figure 8-7) 2
2713642 Tilt Cylinder Hose, (10054), (see Figure 8-7) 4
2716714 Boom Hose, (see Figure 8-7) 2
7111572 Wear Pad, (see Section 2) AR
7079572 Wear Pad, (see Section 2) AR
7082311 Insert, Wear Pad, (see Section 2) AR
7082342 Shim, 0.07, (see Section 2) AR
7082362 Shim, 0.13, (see Section 2) AR
7096772 Spacer, 0.62, (see Figure 2-2) 1
7096702 Spacer, 0.5, (see Section 2) AR
7118892 Quick Attach Pin, (see Figure 2-8) 1
Engine
7139077 Filler Breather Assy, (see Figure 4-2) 1
1001121646 Fan, (if equipped for ULS), (see Figure 4-1) 1
1001098559 Fan, (if equipped for LS), (see Figure 4-1) 1
70024274 Fan Belt, (if equipped for ULS), (see Figure 4-2) 1
70024285 Fan Belt, (if equipped for LS), (see Figure 4-2) 1
70024275 Fan Spacer, (if equipped for ULS), (see Figure 4-1) 1
70024278 Engine Oil Filter Element, (if equipped for ULS), (see Figure 4-2) 1
8036204 Engine Oil Filter Element, (if equipped for LS), (see Figure 4-2) 1
70024279 Dipstick, (if equipped for ULS), (see Figure 4-2) 1
70021584 Dipstick, (if equipped for LS), (see Figure 4-2) 1
Drive Train
1600429 Transmission Selector Control, (see Figure 7-3) 1
1319726 Transmission Filter, (see Figure 5-31) 1
70022241 Wheel End Bushing, (see Section 5) 4
70022218 Front Wheel End Seal, (see Figure 5-8) 2
70022218 Rear Wheel End Seal, (see Figure 5-15) 2
80304173 Wheel Hub Seal, (see Section 5) 4
1319472 Wheel Hub Bearing, (see Section 5) 8
70022203 Axle Wheel Hub O-Ring, (see Section 5) 4
Hydraulic System
8224045 Boom Joystick Assy, (see Figure 7-4) 1
8036295 Boom Extend/Retract Cylinder Seal Kit, (see Figure 9-2) 1
8035386 Boom Lift/Lower Cylinder Seal Kit, (see Figure 9-1) 2
8035780 Attachment Tilt Cylinder Seal Kit, (see Figure 9-3) 1
8035326 Frame Level Cylinder Seal Kit, (see Figure 9-5) 1
8036747 Stabil-Trak Cylinder Seal Kit, (see Figure 9-6) 1
8034695 Tilt Compensation Cylinder Seal Kit, (see Figure 9-4) 2
8036784 Outrigger (Energy) Cylinder Seal Kit, (see Figure 9-7) 2
70022178 Steering Cylinder Seal Kit, (see Section 2) 2
2915023 Swing Carriage Cylinder Seal Kit, (see Figure 9-15) 2
70022041 Side Tilt Carriage Cylinder Seal Kit, (see Figure 9-14) 1
