ELECTRICAL
8042/10042/10054 31200732 10-36
Figure 10-9 Dash/Throttle Harness
WIRELIST FROM/TO INFORMATION WIRELIST FROM/TO INFORMATION
WIRE NAME WIRE NAME SPOOL GAGE COLOR
FROM
COMPONENT PIN
TO
COMPONENT PIN
ON1A GXL18PR GXL18PR 18 18 PURPLE ECM_BULK_23P J P16 B
OFF1A GXL18O GXL18O 18 18 ORANGE ECM_BULK_23P H P16 C
SWRA GXL18Y 18 18 YELLOW YELLOW ECM_BULK_23P K P16 A
THG1 GXL18BK GXL18BK 18 18 BLACK ECM_BULK_23P A P14 A
THP1 GXL18R GXL18R 18 18 RED ECM_BULK_23P B P14 C
THS1 GXL18W GXL18W 18 18 WHITE ECM_BULK_23P C P14 B
THG1
THP1
THS1
ECM_BULK_23P
THP1 THS1 THG1
A B C
THROTTLE
SENSOR
P14
OFF1A ON1A SWRA
A B C
IDLE
VALIDATION
SWITCH
P16
OFF1A OFF1A
ON1A
SWRA
O S
P
Q
R
E
F
L
H
G
T
U
A C
D
B
V
W
J
K
X
N
M
THG1
THP1
THS1
OFF1A
ON1A
SWRA
HTR TAIL
HTR/HRN/CHARGE FUSE HTR/HRN/CHARGE FUSE
CHG2
HTR
CHG
CHG
CHG
HTR
CHG2
GXL16ORG GXL16ORG 16 ORANGE ECM_BULK_23P X 7 SPLICE
GXL12ORG GXL12ORG 12 ORANGE HTR TAIL 1 7 SPLICE
GXL12ORG 12 ORANGE HTR/HRN/CHARGE FUSE HTR/HRN/CHARGE FUSE 1 7 SPLICE SPLICE
7
3
4
5
5
6
7
16
17
18
19
13
14
15
PH5640
