HYDRAULIC CIRCUITS
31200732
8042/10042/10054
8-19
Figure 8-8 Auxiliary Hydraulic Circuit
Item
Part Number
Qty.
Description
Rev.
1001121399
Ref
AUXILIARY HYDRAULICS INSTALLATION, (not available to order, see items 1
thru 15 for service)
C
1
2230044
2
ADAPTER, 90 DEGREES
2
2716713
2
HOSE ASSY
4
8307004
1
LOCKWASHER, 5/16
5
8310009
1
HEX HD CAPSCREW, 5/16-18X2
6
8750012
3
STACKING BOLT
9
8750027
4
TWIN CLAMP SET, 0.84 DIA
11
2220373
1
CONNECTOR, (includes o-ring)
12
2220596
1
ELBOW, 90 DEGREES, (include o-ring)
13
8765204
1
ELBOW, 90 DEGREES, (swivel nut)
14
8769128
1
TWIN COVER PLATE
15
1001121396
2
HOSE ASSY
101
2713082
2
HOSE ASSY, (8042 & 10042), (see item 201 for 10054)
102
2230025
2
STRAIGHT BULKHEAD UNION
103
2220651
2
STRAIGHT CONNECTOR, (swivel nut), (includes o-ring)
104
91403413
1
FEMALE QUICK DISCONNECT, (includes items 105 thru 107)
105
8640029
1
NOSE SEAL
106
8640028
1
COUPLER BODY SEAL
107
8640032
1
COUPLER BODY SEAL BACK-UP RING
108
8420055
1
DUST PLUG, #8
109
91403414
1
MALE QUICK DISCONNECT, (includes item 110)
110
8640029
1
NOSE SEAL
111
8420053
1
DUST CAP, #8
112
8310081
2
HEX HD CAPSCREW, 5/16-18X5
113
8307004
2
LOCKWASHER, 5/16
114
8307203
2
FLAT WASHER, 5/16
115
7111402
1
CLAMP SUPPORT
116
8307005
2
LOCKWASHER, 5/16
117
8303622
2
HEX HD CAPSCREW, 3/8-16X2, GR5
118
8769161
2
SINGLE CLAMP, 0.75 ID, (8042 & 10042)
8750003
2
SINGLE CLAMP, 0.62 ID, (10054)
119
7300674
1
AUXILIARY TUBE ASSY
120
7300675
1
AUXILIARY TUBE ASSY
121
8760465
4
BULKHEAD LOCKNUT
122
8526048
1
LOCTITE
®
545
TM
, (apply to items 119, 120 & 121)
123
8303739
3
HEX HD CAPSCREW, 5/16-18X2-1/4
124
8769123
3
TWIN CLAMP COVER PLATE
125
8769122
6
TWIN CLAMP, 0.62 ID, (two halves)
126
8750011
3
TWIN CLAMP STACK BOLT
127
8750017
3
TWIN CLAMP LOCK PLATE
201
Ref
HOSE & CARRIER ASSY, (includes items 202 thru 204), (10054),
(see Figure 8-7 for details)
202
Ref
HOSE ASSY, (see Figure 8-7 for details)
203
Ref
HOSE CARRIER, (see item 201 for service), (see Figure 8-7 for details)
204
Ref
TIE WRAP, (see Figure 8-7 for details)
301
Ref
MAIN CONTROL VALVE, (see Figure 9-9 for details)
