Parts listing – ARB 4450220 User Manual
Page 3
Last Rev Date: 17/05/2007
Page 3 of 10
Fitting instructions# 3783284
Copyright © 2005 by ARB Corporation Limited. All rights reserved, this document must not be reproduced without the express authority of ARB Corporation Ltd
PARTS LISTING
APPLICATION.
PART NO.
QTY
DESCRIPTION
3199987L
1
PLATE ANGLE LH (LWB)
3199987R
1
PLATE ANGLE RH (LWB)
6151412
12
M6 X 16 BUTTON HEAD CAP SCREW
4584295
12
M6 WASHER BLACK
ANGLE TRIM TO VEHICLE (LWB)
6151128
8
M6 FLANGE NUT
3199988L
1
PLATE ANGLE LH (SWB)
3199988R
1
PLATE ANGLE RH (SWB)
6151412
8
M6 X 16 BUTTON HEAD CAP SCREW
4584295
8
M6 WASHER BLACK
ANGLE TRIM TO VEHICLE (SWB)
6151128
4
M6 FLANGE NUT
3199943
2
CAGE PLATE M10 (225mm)
6151304
2
CAGE NUT M10
6151204
2
BOLT M10 X 35mm
4581040
2
WASHERS M10
FRONT MOUNT BRACKET TO
CHASSIS (LHS & RHS)
4581048
2
SPRING WASHERS M10
3199943
2
CAGE PLATE M10 (225mm)
3199848
2
CAGE PLATE M12
6151304
2
CAGE NUT M10
6151305
2
CAGE NUT M12
4581040
2
WASHERS M10
4581007
2
WASHERS GOLD M12
4581048
2
SPRING WASHERS M10
4581050
2
SPRING WASHERS M12
6151255
2
BOLT M12 X 1.75 X 40mm
REAR MOUNT BRACKET TO
CHASSIS (LHS & RHS)
6151232
2
BOLT M10 X 30mm
3199944
4
CAGE PLATE M10 (335mm)
6151304
4
CAGE NUT M10
4581040
4
WASHERS M10
4581048
4
SPRING WASHERS M10
MIDDLE MOUNT BRACKET TO
CHASSIS (LHS & RHS)
6151204
4
BOLT M10 X 35mm
6151098
2
BOLT M12 X 1.5 X 40
4581007
4
WASHER / PACKER M12 GOLD
FRONT MOUNT BRACKET
(LHS & RHS) MANUAL
TRANSMISSION VARIANT
4581050
2
SPRING WASHER
MISCELLANEOUS
215637
6500002
2
2
STICKER “ARB”
RUBBER PLUG 60.3mm TUBE
