ARB 3934020 User Manual
Page 6
13/06/06
Page 6 of 13
3782863
9.
1. Using a 12mm drill bit, drill through the two
slot holes at the front into the chassis cross
member.
10.
1. Feed the captive nut plate through the hole in
the cross member and fasten using M10
bolts, flat washers and spring washers.
11.
1. Using a 13mm drill bit, drill through the holes
in the outside bracket and into the chassis
rail.
