FITTING REQUIREMENTS
REQUIRED TOOLS FOR FITMENT OF PRODUCT:
Metric Spanner and Socket sets
Allen key set
Phillips head screwdriver
Dia 10.0 drill bit
Electric drill 13mm chuck
HAVE AVAILABLE THESE SAFETY ITEMS WHEN FITTING PRODUCT
:
Protective eyewear
Hearing protection
NOTE: ‘WARNING’ notes in the fitting procedure relate to OHS situations, where to avoid a
potentially hazardous situation it is suggested that protective safety gear be worn or a safe work
procedure be employed. If these notes and warnings are not heeded, injury may result.
FASTENER TORQUE SETTINGS:
SIZE
Torque Nm
Torque lbft
M6 9Nm
4lbft
M8 22Nm
16lbft
M10 44Nm
32lbft
M12 77Nm
57lbft
NOTE: Shipping brackets connecting bull bar to pallet and
associated fasteners are not intended to be reused in fitted
bar assembly.
