27/9/05 Page 7 of 14 3783168
1.12 Fit M12 bolt, nut and washer set into
spacer, and M12 bolt and washer set into
top of bracket and flange and nip up (not
tight)
1.13 Fit M10 bolt, nut and washer set into
gusset and do up tight.
Tighten all other bolts starting from long
bolt through chassis, bolt from underneath,
top bolts etc.
1.14 Check that brackets are still parallel to
each other, if not adjust and tighten bolts.
Fit grille and shroud back into
position.
