27/9/05 Page 14 of 14 3783168
4.5 Wire up the indicator and clearance lamp
assemblies. Use scotch locks to splice
cables to existing indicator and clearance
lamp wiring and cable tie securely.
If fog lights are to be installed, mount
positions are on lower pan area between
winch opening and high lift jack position.
Refer to the Warn winch manual for
vehicle wiring instructions.
Ensure that electrical cables are installed
well clear of sharp, hot or moving objects.
Secure the winch cables to the vehicle
and winch bumper with the supplied cable
ties.
