4 Installing the Air System
26
4.1 Mounting the Solenoid
4.1.1
Connection to an ARB Air Compressor (Fig.16.)
F
5HPRYHRQHRIWKH´%63SOXJVIURPLWVSRUWLQWKH compressor
tank.
F $SSO\7HIORQSDVWHWRWKHQLSSOH´;´%63DQGLQVHUWLWLQWR
the port and tighten.
F Apply Teflon paste to the free end of the nipple.
F $VVHPEOHWKHLQOHWSRUWVLGHRIWKHVROHQRLGVWDPSHGZLWKDµ¶
onto the nipple and tighten. The solenoid should be rotated into a
position that does not obstruct any other ports on the compressor
tank.
NOTE : The solenoid exhausts compressed air through the
center of the black retaining cap when the Air Locker
is disengaged. Make sure this orifice cannot be
obstructed.
F Apply Teflon paste to the threads of the 5mm push-­in fitting and
DVVHPEOHLWLQWRWKHVROHQRLGRXWOHWSRUWVWDPSHG³´DQGWLJKWHQ
Figure 16.
ARB
Air Compressor
