PERFORMANCE DATA (cont)
COOLING CAPACITIES (cont)
580F072 (6 TONS)
Temp (F)
Air Entering
Condenser
(Edb)
Air Entering Evaporator — Cfm/BF
1800/0.06
2100/0.08
2400/0.09
3000/0.11
Air Entering Evaporator — Ewb (F)
72
67
62
72
67
62
72
67
62
72
67
62
75
TC
86.6
80.0
73.6
87.8
80.3
73.2
90.8
84.1
77.2
93.2
86.6
79.7
SHC
42.2
52.3
62.2
43.0
53.9
65.5
46.5
59.6
71.6
50.1
66.4
78.7
kW
5.48
5.33
5.21
5.69
5.50
5.32
5.59
5.44
5.29
5.66
5.51
5.35
85
TC
84.1
77.4
71.0
84.0
77.2
69.5
87.8
81.2
74.5
90.1
83.5
77.3
SHC
41.4
51.3
61.1
41.7
53.1
64.0
45.5
58.6
70.3
49.4
65.4
76.7
kW
6.17
6.00
5.85
6.21
6.04
5.83
6.27
6.11
5.94
6.35
6.19
6.02
95
TC
81.6
74.7
68.5
81.0
73.5
66.3
84.8
78.2
71.8
87.0
80.4
74.8
SHC
40.6
50.3
60.0
40.8
51.8
62.8
44.6
57.6
69.1
48.7
64.5
74.7
kW
6.86
6.67
6.49
6.78
6.54
6.33
6.95
6.77
6.59
7.03
6.86
6.69
105
TC
78.4
71.8
65.6
76.8
69.7
62.5
81.6
74.9
68.9
83.3
76.9
72.1
SHC
39.4
49.2
58.7
39.4
50.3
61.1
43.5
56.4
67.4
47.4
63.1
72.0
kW
7.60
7.39
7.20
7.30
7.05
6.80
7.72
7.50
7.31
7.77
7.59
7.41
115
TC
75.1
68.7
62.5
72.5
65.5
58.7
78.0
71.5
66.1
79.5
73.3
69.3
SHC
38.1
47.9
57.2
37.9
48.7
58.7
42.3
55.1
65.5
46.3
61.6
69.2
kW
8.36
8.14
7.93
7.81
7.53
7.27
8.49
8.25
8.06
8.55
8.33
8.18
580F073 (6 TONS)
Temp (F)
Air Entering
Condenser
(Edb)
Air Entering Evaporator — Cfm/BF
1800/0.06
2100/0.07
2400/0.09
3000/0.11
Air Entering Evaporator — Ewb (F)
72
67
62
72
67
62
72
67
62
72
67
62
75
TC
81.3
77.8
71.3
82.7
78.7
72.9
84.2
79.7
74.6
85.3
82.5
76.7
SHC
38.2
51.3
61.6
40.2
54.2
65.9
42.3
57.1
70.2
43.7
64
76.4
kW
4.69
4.63
4.52
4.73
4.65
4.56
4.77
4.67
4.6
4.8
4.75
4.63
85
TC
78.8
75.6
69
81.1
77.1
70.7
83.3
78.6
72.3
85
80.5
75
SHC
37.7
50.4
60.5
40
53.9
64.9
42.2
57.5
69.2
44.3
63.6
74.9
kW
5.21
5.16
5.05
5.27
5.2
5.09
5.34
5.24
5.13
5.39
5.29
5.17
95
TC
77.1
73.3
66.9
79.2
74.8
68.5
81.3
76.2
70.1
82
78
73.3
SHC
37
49.9
59.7
39.4
53.3
64
41.8
56.8
68.3
43.5
63.4
73.2
kW
5.8
5.78
5.65
5.87
5.81
5.7
5.94
5.85
5.74
5.95
5.88
5.8
105
TC
75.4
70.7
62.9
76.6
72.1
64.8
77.9
73.4
66.7
79.7
74.9
70.9
SHC
36.7
48.7
58.2
38.6
52.3
62.2
40.6
55.9
66.3
43
62.4
70.9
kW
6.49
6.45
6.26
6.53
6.48
6.32
6.56
6.51
6.38
6.61
6.53
6.46
115
TC
72.1
67.9
59
73.6
69
61.1
75.2
70.1
63.3
76.7
71.9
68.1
SHC
35.3
47.5
57.2
37.6
51.2
60.2
39.9
54.8
63.3
42.2
61.5
68.1
kW
7.2
7.17
6.94
7.25
7.18
7.01
7.29
7.2
7.08
7.35
7.26
7.15
580F090 (7
1
/
2
TONS)
Temp (F)
Air Entering
Condenser
(Edb)
Air Entering Evaporator — Cfm/BF
2250/0.07
2800/0.09
3000/0.10
3750/0.12
Air Entering Evaporator — Ewb (F)
72
67
62
72
67
62
72
67
62
72
67
62
75
TC
102.8
94.8
86.2
105.8
98.2
90.0
106.4
99.0
90.8
109.2
101.6
93.6
SHC
49.4
61.8
73.2
52.6
67.8
81.6
53.6
69.8
84.0
58.2
77.4
92.2
kW
7.14
6.82
6.50
7.28
6.98
6.68
7.32
7.04
6.72
7.46
7.18
6.86
85
TC
98.2
90.2
81.6
101.8
93.6
85.2
102.6
94.4
86.0
104.6
96.8
89.6
SHC
48.0
60.2
71.2
51.6
66.4
79.6
52.8
68.6
82.0
56.8
76.0
89.4
kW
7.66
7.34
7.00
7.82
7.50
7.18
7.86
7.54
7.22
7.98
7.68
7.40
95
TC
93.8
85.2
76.6
97.0
88.4
80.0
97.6
89.0
81.2
99.4
91.2
85.2
SHC
46.4
58.2
68.8
50.2
64.6
77.2
51.4
66.8
79.0
55.6
74.4
85.2
kW
8.18
7.84
7.48
8.36
8.00
7.64
8.40
8.04
7.70
8.50
8.16
7.92
105
TC
88.4
79.8
70.8
91.0
82.8
74.6
91.6
83.4
76.0
93.8
85.4
80.6
SHC
44.6
56.2
66.0
48.2
62.6
74.2
49.4
64.8
75.6
54.2
72.4
80.6
kW
8.68
8.30
7.98
8.80
8.46
8.14
8.86
8.50
8.20
8.98
8.64
8.42
115
TC
82.8
73.8
66.0
85.2
76.8
69.6
85.6
77.4
71.0
87.6
79.4
76.0
SHC
42.6
53.8
63.2
46.4
60.4
69.6
47.8
62.6
71.0
52.8
70.4
75.8
kW
9.16
8.78
8.42
9.30
8.92
8.64
9.34
8.96
8.72
9.48
9.10
8.94
