274
PERFORMANCE DATA (cont)
EVAPORATOR FAN MOTOR SPECIFICATIONS — 581A210-300
LEGEND
ACCESSORY/FIOP STATIC PRESSURE (in. wg) — 581A210-300
LEGEND *The static pressure must be added to the external static pressure. The sum
and the evaporator entering-air cfm should then be used in conjunction with
the Fan Performance tables to determine blower rpm and watts.
UNIT
581A
DRIVE ORIENTATION
MOTOR
P/N
NOMINAL
HP
VOLTAGE
MAX
WATTS
EFFICIENCY
%
MAX
BHP
MAX
BkW MAX
AMPS
210
Low Vertical
HD60FK651 3.7 208 3698 85.8 4.25 3.17 10.6
HD60FK651 3.7 230 3698 85.8 4.25 3.17 9.6
HD60FK651 3.7 460 3698 85.8 4.25 3.17 4.8
HD58DL575 3 575 3149 81.7 3.45 2.57 3.9
High Vertical
HD60FL650 5 208 4900 87.5 5.75 4.29 16.7
HD60FL650 5 230 4900 87.5 5.75 4.29 15.2
HD60FL650 5 460 4900 87.5 5.75 4.29 7.6
HD60FL575 5 575 4900 87.5 5.75 4.29 6.1
Low Horizontal
HD60FK651 3.7 208 3698 85.8 4.25 3.17 10.6
HD60FK651 3.7 230 3698 85.8 4.25 3.17 9.6
HD60FK651 3.7 460 3698 85.8 4.25 3.17 4.8
HD58DL575 3 575 3149 81.7 3.45 2.57 3.9
High Horizontal
HD60FL650 5 208 4900 87.5 5.75 4.29 16.7
HD60FL650 5 230 4900 87.5 5.75 4.29 15.2
HD60FL650 5 460 4900 87.5 5.75 4.29 7.6
HD60FL575 5 575 4900 87.5 5.75 4.29 6.1
240
Low Vertical
HD60FL650 5 208 4900 87.5 5.75 4.29 16.7
HD60FL650 5 230 4900 87.5 5.75 4.29 15.2
HD60FL650 5 460 4900 87.5 5.75 4.29 7.6
HD60FL575 5 575 4900 87.5 5.75 4.29 6.1
High Vertical
HD62FL650 7.5 208 7267 88.5 8.63 6.43 24.2
HD62FL650 7.5 230 7267 88.5 8.63 6.43 22
HD62FL650 7.5 460 7267 88.5 8.63 6.43 11
HD62FL575 7.5 575 7267 88.5 8.63 6.43 9
Low Horizontal
HD60FK651 3.7 208 3698 85.8 4.25 3.17 10.6
HD60FK651 3.7 230 3698 85.8 4.25 3.17 9.6
HD60FK651 3.7 460 3698 85.8 4.25 3.17 4.8
HD60FL575 5 575 4900 87.5 5.75 4.29 6.1
High Horizontal
HD60FL650 5 208 4900 87.5 5.75 4.29 16.7
HD60FL650 5 230 4900 87.5 5.75 4.29 15.2
HD60FL650 5 460 4900 87.5 5.75 4.29 7.6
HD60FL575 5 575 4900 87.5 5.75 4.29 6.1
300
Mid-Low Vertical
HD60FL650 5 208 4900 87.5 5.75 4.29 16.7
HD60FL650 5 230 4900 87.5 5.75 4.29 15.2
HD60FL650 5 460 4900 87.5 5.75 4.29 7.6
HD60FL575 5 575 4900 87.5 5.75 4.29 6.1
Mid-High Vertical
HD62FL650 7.5 208 7267 88.5 8.63 6.43 24.2
HD62FL650 7.5 230 7267 88.5 8.63 6.43 22
HD62FL650 7.5 460 7267 88.5 8.63 6.43 11
HD62FL575 7.5 575 7267 88.5 8.63 6.43 9
Mid-Low Horizontal
HD60FL650 5 208 4900 87.5 5.75 4.29 16.7
HD60FL650 5 230 4900 87.5 5.75 4.29 15.2
HD60FL650 5 460 4900 87.5 5.75 4.29 7.6
HD60FL575 5 575 4900 87.5 5.75 4.29 6.1
Mid-High Horizontal
HD62FL650 7.5 208 7267 88.5 8.63 6.43 24.2
HD62FL650 7.5 230 7267 88.5 8.63 6.43 22
HD62FL650 7.5 460 7267 88.5 8.63 6.43 11
HD62FL575 7.5 575 7267 88.5 8.63 6.43 9
BHP — Brake Horsepower
BkW — Brake Kilowatts
COMPONENT
CFM
4,000 4,500 5,000 5,500 6,000 6,500 7,000 7,500 8,000 8,500 9,000 9,500 10,000 10,500 11,000 11,500 12,000
Economizer 0.02 0.03 0.04 0.05 0.06 0.07 0.08 0.09 0.10 0.11 0.12 0.13 0.15 0.16 0.17 0.19 0.20
FIOP — Factory-Installed Option
