Page 162
162
EVAPORATOR-FAN MOTOR EFFICIENCY —
581C024-060
*Single phase/3 phase.
NOTES:
1. Convert bhp to watts using the following formula:
2. The EPACT (Energy Policy Act of 1992) regulates energy require-
ments for specific types of indoor fan motors. Motors regulated by
EPACT include any general purpose, T-frame (three-digit, 143 and
larger), single-speed, foot mounted, polyphase, squirrel cage
induction motors of NEMA (National Electrical Manufacturers
Association) design A and B, manufactured for use in the United
States. Ranging from 1 to 200 Hp, these continuous-duty motors
operate on 230 and 460 volt, 60 Hz power. If a motor does not fit
into these specifications, the motor does not have to be replaced
by an EPACT-compliant energy-efficient motor. Variable-speed
motors are exempt from EPACT compliance requirements. There-
fore, the indoor fan motors for Bryant 581C024-060 units are
exempt from these requirements.
ACCESSORY/FIOP STATIC PRESSURE* (in. wg) — 581C024-060
LEGEND
*The static pressure must be added to external static pressure. The
sum and the evaporator entering-air cfm should be used in conjunction
with the Fan Performance tables to determine indoor blower rpm and
watts.
581C - OPTION/ACCESSORY WEIGHTS
UNIT SIZE
581C
EFFICIENCY%
024, 036, 048
75
060
74/84*
watts =
bhp (746)
motor efficiency
COMPONENT
CFM
600
800
1000
1250
1500
1750
2000
2250
2500
2750
3000
Vertical EconoMi$er IV and EconoMi$er2
0.10
0.20
0.35
0.045
0.065
0.08
0.12
0.145
0.175
0.22
0.255
Horizontal EconoMi$er IV and EconoMi$er2
—
—
—
—
—
0.1
0.125
0.15
0.18
0.225
0.275
FIOP —
Factory-Installed Option
Option / Accessory
024
036
048
060
lb
kg
lb
kg
lb
kg
lb
kg
Perfect Humidity Dehumidification System
13
6
15
7
23
10
25
11
Power Exhaust - vertical
50
23
50
23
50
23
50
23
Power Exhaust - horizontal
30
14
30
14
30
14
30
14
EconoMi$er ( IV or 2)
50
23
50
23
50
23
50
23
Two Position damper (25%)
22
10
22
10
22
10
22
10
Two Position damper (100%)
39
18
39
18
39
18
39
18
Manual Dampers
12
5
12
5
12
5
12
5
Hail Guard (louvered)
16
7
16
7
16
7
16
7
Hail Guard (standard hood assembly)
25
11
25
11
25
11
25
11
Cu/Cu Condenser Coil
5
2
6
3
13
6
13
6
Cu/Cu Condenser and Evaporator Coils
10
5
12
5
19
9
21
10
Roof Curb (14-in. curb)
115
52
115
52
115
52
115
52
Roof Curb (24-in. curb)
197
89
197
89
197
89
197
89
58
1C02
4-
060
