JUNE 13, 2001 9 MT1828 E & G
CONVECTION COMPONENTS
SEE PICTURES ON PAGE 10
Ref. Part
No. No. Description
48 M7156 Motor & Blower Assy., CW, 50/60 HZ (Qty 2)
M5944 Insulation Kit, Motor (2 Blower) (Qty 1)
49 M6807 Plate Assy., Air (Upper) (Qty 1)
50 M6805 Plate Assy., Block Off (Upper) (Nozzle)
51 M5820 Nozzle Assy., (Under Conveyor) (Qty 3)
52 M6828 Nozzle Assy., (Under Conveyor) (Qty 2)
M4131 Block Off Plate
(Integral Control Ovens)
M9639 Plate,Block Off (Nozzle) for Donato's
M9640 Air Plate Assy., for Donato's
39 M6969 Tube Assy., Flame (Qty 1)
CONVEYOR COMPONENTS
SEE PICTURES ON PAGE 10 OR 3&4
Ref. Part
No. No. Description
20 M6337 Belt, Wire S/S 18" (Per Foot)
(Total Length 9 FT)
23 M9787 Fuse, Armature, 250MA, 250V
(Replaces part M2316, DOMESTIC ONLY)
22 M2254 Fuse, Line, Bodine Board, 5 AMP, 125V
M3301 Capacitor, Digital Speed Control Board
21 ; FW502 Digital Speed Control Board, Bodine
Recond
NOTE: M2379 is no longer available
; M10099 Conveyor Motor & Control Kit, Brushless
(for Computerized Ovens) *See Note
21 ; M10081 Conveyor Control, Brushless *See Note
24 ; M10082 Conveyor Motor, Brushless *See Note
*NOTE: You must install the Brushless Kit BEFORE
you purchase the new brushless motor or
control separately.
32 ; M6192 Bracket (For M10082)
M2500 Brush Set, Bodine (Qty 1)
25 M5805 Conveyor Assy. (Qty 1)
26 M4815 Shaft, Conveyor Drive(Qty 1)
27 M4816 Shaft, Conveyor Idle (Qty 1)
28 M4817 Bearing, Rulon (Qty 4)
M4812 Bushing, for Bearing M4817 (Qty 4)
29 M4818 Sprocket, Wire Belt (Qty 10)
30 M6121 Pulley, Timing 1/5P 3/8 Wide
(Sprocket)(Qty 1)
31 ; M6808 Belt, Timing (Qty 1) (Marked "220XL")
M9862 Chain Guard (Only on units after 07/16/99
or S.N. 071699GE040T)
EXTERIOR COMPONENTS
SEE PICTURES ON PAGE 10
Ref. Part
No. No. Description
53 M10181 Sandwich Door Assy, 17"x5", Solid w/
handle Replaces M4587
53 M10243 Sandwich Door Assy, 17"x5", Glass w/
handle Replaces M9237
NOTE: For ALL ovens, if you need a new sandwich
door order part M10181, Door Assy,
or part M10243, Door Assy.
M10128 Handle Kit, 16 1/2" For M10181 & M10243
For ovens after 12/05/00, or converted units
with 16 1/2" handle
M2188 Handle Assy, 2" black plastic, for Sandwich
Door For ovens before 12/05/00
NOTE: To convert from a 2" to a 16 " handle you
must purchase a complete door assy
M10181 or M10243.
55 M4581 Plate, Pivot RH Slotted (Qty 1)
56 M4582 Plate, Pivot LH Slotted (Qty 1)
57 M7118 Crumb Pan, Idle (Single Section) (Qty 1)
M7117 Crumb Pan, Idle (Top Section) (Qty 1)
58 M7116 Crumb Pan, Drive (Qty 1)
59 M6792 Product Stop (Qty 1)
61 M10056 Product Extension, 12", Drive & Idle Side
(Qty 2 per oven)
62 M5880 Panel Assy., Access (Power)
63 M6035 Latch, Access Panel Assy. (Qty 1)
64 M6925 Air Curtain, Drive Side (Qty 1)
M6945 Air Curtain, Idle Side (Qty 1)
M6955 Heat Shield Kit
M5899 Heat Shield, Only
M6813 Chimney Kit, Single (Qty 1)
M6814 Chimney Kit, Double (Qty 1)
M6815 Chimney Kit, Triple (Qty 1)
M5847 Body Back (Qty 1)
M5953 Stand, 24" S/S w/casters (Sgl & Dbl Ovens)
M2532 Triple Base w/casters (Qty 1)
M9106 Pins, Stacking (Set of 4)
M9083 Stacking Kit
21826 Installation Hose, 36" (Qty 1)
21242 Installation Hose, 48" (Qty 1)
65 16469 Nameplate, Blodgett 7-3/4" (Qty 1)
M9931 Kit, Integral to Remote Mount, Computer
Conversion (does not include computer)
