MT1828E & MT1828G

June 13, 2001

;

ASAP Distributor Required Stocking Parts

ELECTRICAL COMPONENTS - Cont'd

Ref.

Part

No.

No.

Description

11 ; 11204

Terminal Block, 3 Pole (Qty 1) Gas

98

M3714

Terminal Block, 3 Pole (Qty 1) Elec

99

M3715

Terminal Block, 1 Pole (Qty 1) Elec (Ground)

12 ; M0593

Terminal Block, 2 Pole (Qty 1) or (CE Qty 2)

13 ; M2469

Fan, Axial 110 CFM 4-1/2" (Qty 5)

14

22718

Fan Guard & Hardware (Qty 2)

M0572

Cord, Axial Fan 30" Power (Qty 5)

;

M6576

Plate Assy., Control MT1828E

M6578

Plate Assy., Control MT1828G

M1694

Cord Set & Plug Assy., 10' MT1828G

M7955

Cord Set & Plug Assy., 10' MT1828E

M0772

Receptacle, Twist Lock

15

M0708

Contactor, 3 Pole, 120V Coil (Fan)

16

M7159

Contactor, 3 Pole, 30 AMP, 120V 3PH
(Element)

M6868

Contactor, 2 Pole, 60 AMP, 120V 1PH
(Element)

M4988

Fuse, 5 AMP, 300V, SC-5 (Qty 2)

17

M0158

Fuse Holder (Qty 2) Elec Ovens

M8559

Conv Kit, 208V 3PH to 240V 1PH

18

M6097

Element Assy., 208V, 3 PH (Qty 1)

18

M6099

Element Assy., 208V, 1 PH (Qty 1)

18

M6101

Element Assy., 220V (Qty 1)

18

M6098

Element Assy., 240V, 3 PH (Qty 1)

18

M6100

Element Assy., 240V, 1 PH (Qty 1)

18

M6102

Element Assy., 240V (Qty 1)

M9839

Element, Individual 208V

M9840

Element, Individual 220V

M9841

Element, Individual 240V

19

90034

Lug, Grounding (Qty 1) Gas Ovens

M9422

Pressure Switch

M9705

Polyurethane Tubing, used w/pressure
switch (Per Foot, Total 3 FT)

M3118

Harness (back of control to motors)

M3120

Harness (Contactor to control box)

ELECTRICAL COMPONENTS

Ref.

Part

No.

No.

Description

1

;

M6474

Computer Control Kit,Closed Loop SB(Qty 1)

1

;

FW525

Computer Control Kit,Closed Loop SB(Qty 1)
(Reconditioned)

M9692

DAC Board (for M6474)

M10049

Decal & Control Membrane
(for M6474/FW525) SB

M3175

Lexan Decal only, SB

60

M10197

Remote Mounting Support Kit, for Computer
(sgl, dbl & tpl ovens) Replaces M3314

2

;

M7427

Probe, Temperature RTD, 500 OHMS 6"
(Qty 1) (Before 7/15/99 or S.N. 071599GE066T)

Note:

Use this probe if oven has not been
burner retrofitted.

M9607

Probe, Temperature RTD, 500 OHMS 14"
(Qty 1) (After 7/15/99 or S.N. 071599GE066T)

Note:

Use this probe if oven has been
burner retrofitted.

M7202

Conversion Kit, Open to Closed Loop(Qty 1)

M10035

Silicone Compound (for cables)

M3347

Cable, Computer Control, 25 Pin, 10' (Qty 1)

M3348

Cable, Computer Control, 9 Pin, 10' (Qty 1)

M3490

Cable, Computer Control, 25 Pin, 50' (Qty 1)

M3491

Cable, Computer Control, 9 Pin, 50' (Qty 1)

M5661

Bracket Assy, Cable Clamp

M9262

Jack Screw (for harness mounts)

M3349

Harness, w/socket, Inter-Connecting DC
Drive, 3-Wire (For 9 Pin) (Qty 1)

M7237

Harness, w/socket, Relay Board
(For 25 Pin) (Qty 1)

M9985

Relay Harness & Jack Screw Kit (25 pin)

;

M0984

Pick-Up, PV-2 (Qty 1)

;

M7236

Board, Relay/Transformer (Qty 1)

3

;

22672

Relay, Control (Qty 4)

4

;

M3352

Transformer, 120V to 24V (Qty 1)

5

22593

Transformer, 208/230V to 115V (Qty 1)

37 ; 24356

Transformer, 120V to 24V (Qty 1)(for M7885)

6

;

20349

Buzzer, 120V (Qty 1)

7

;

36066

Thermostat, High Limit Kit (Qty1)

M9867

Probe Well Assy

8

;

M1362

Snap Disc, L140-20F, 2 Pole SPST
(Control Compartment)

9

;

M2453

Snap Disc, L140-20F, 3 Pole SPDT
(Blower Compartment)

10 ; M6044

Snap Disc, L110-20F, 3 Pole SPDT (Computer)

;

M0152

Contact, Emergency Stop Switch (Qty 1)

;

M3296

Activator, Emergency Stop Switch
(Mushroom Shape) (Qty 1)

;

M3297

Nameplate, Emergency Stop (Qty 1)

IMPORTANT: When ordering parts, please provide the model, gas type
and serial number of the oven. The identification plate is located on
the left side of the combustion compartment and, also, above the control
panel under the ledge.
