Blodgett CONVEYOR OVEN REPLACEMENT PARTS MT1828E - Manual (Page 12)

EXCLUSIVE TO EXPORT 50 HZ
Ref. Part
No. No. Description
34 M7815 Shroud, Flame Sensor (Qty 1) CE
105 M9517 Probe, Flame Sensing (Qty 1) CE
(After 7/15/99 or S.N. 071599GE066T)
Use if oven has been burner retrofitted.
2 M7427 Probe, RTD, 500 OHMS (Qty 1) 6"
(After 7/15/99 or S.N. 071599GE066T)
M9607 Probe, RTD 500 Ohms 14"
(After 7/15/99 or S.N. 071599GE066T)
Use if oven has been burner retrofitted.
M9530 Ignitor, Direct Spark (Qty 1) CE
(After 7/15/99 or S.N. 071599GE066T)
Use if oven has been burner retrofitted.
84 M6448 Filter, Noise (Qty 1) CE
85 M6449 Filter, Noise (Qty 1) CE
86 20350 Buzzer, 240V (Qty 1) CE
101 M7157 Complete Burner Assy. CE
87 16037 Indicator Light, 250V, Red, Round (Qty 2)
CE
103 M3295 Thermostat, High Limit (Man Reset) CE
70 M0595 Air Pressure Switch CE & Gen Exp
Gas Ovens only
M9978 Conversion Kit, Air Pressure Differential
Switch CE & Gen Exp Gas Ovens Only
(Replaces M3330 or M2819)
88 M9422 Air Pressure Differential Switch, switch
only CE & Gen Exp Gas Ovens only
M9705 Polyurethane Tubing, used w/pressure
switch (Per Foot, Total 3 FT) CE & Gen Exp
89 M2247 Contactor, 240V, 50 HZ (Qty 1) CE
91 M3172 Time Delay, 2 Second (Qty 1) CE
M3173 Timer, 10 second fixed (Qty 1) CE
92 16775 Relay, SPST, 240V, 30 Amp. (Qty 1) CE
93 M6519 Relay, Time Delay (Qty 1) CE
96 M9107 Blower Motor, Combustion 50 HZ (Qty 1)
CE
97 M7230 Plate Assy., Air (Qty 1) CE
M3167 Fuseholder, Type HTB-36M CE
M8592 Fuse, Export 5AMP CE
M4988 Fuse, 5AMP, 300V, Class G
M2316 Fuse, Armature, 200MA, 250V (Qty 1) CE
M2630 Fuse, Line, Bodine Board, 500MA, 250V
(Qty 1) CE
45 M7170 Transformer, 208/460V-120 CE & NON CE
M8744 Leg/ Casters, 17 1/4" (Set of 4) CE
M8745 Leg/Casters, 23 1/4" (Set of 4) CE
EXCLUSIVE TO VERSION AA
Philippines & Korea
Ref. Part
No. No. Description
M9150 Transformer, 220V/110V
M6924 Decal, Lexan Control
EXCLUSIVE TO EXPORT 50 HZ
Ref. Part
No. No. Description
90 M3153 Speed Control Board, Digital
(Gas ovens only)
24 M3128 Conveyor Drive Motor, 180V
(Gas ovens only)
M6888 Element Assy., 220/380V, 1 PH (Qty 1)
M6101 Element Assy., 220/380V, 3 PH (Qty 1)
M6100 Element Assy., 240/415V, 1 PH (Qty 1)
M6102 Element Assy., 240/415V, 3 PH (Qty 1)
66 M7156 Motor & Blower Assy., CW 50/60 HZ (Qty 2)
67 M6527 Gas Valve, Nat 230V (Qty 1)
67 M6528 Gas Valve, LP 230V (Qty 1)
33 M7066 Orifice Assy, Nat Gen Exp CE
Units before 02/28/00
33 R5059 Orifice Assy, LP Gen Exp CE
Units before 02/28/00
102 M10425 Orifice Assy, Main Burner, Nat Gen Exp CE
Replaces M10124 Units after 02/28/00
102 M10426 Orifice Assy, Main Burner, LP Gen Exp CE
Replaces M10125 Units after 02/28/00
M10177 Gas Conversion Kit, LP to Nat CE
**Except France and Belgium
M10178 Gas Conversion KIt, Nat to LP CE
**Except France and Belgium
M10179 Gas Conversion Kit, LP to Nat CE
**France and Belgium only
M10180 Gas Conversion Kit, Nat to LP CE
**France and Belgium only
M6868 Contactor, Mercury 120V (Qty 1)
71 M6029 Connector, Liquid Tight (Qty 1)
72 R0166 Terminal Block, Ground (Qty 1)
73 M4542 Terminal Block, Power (Qty 1) CE
74 R1580 Stop, End (Qty 1)
75 M7880 Computer Control Kit Closed Loop SB, CE
M8559 Wire Conversion Kit, 208V, 1PH, 3Wire
to 220/240V, 1PH,2Wire
76 M7282 Board, Relay/Transformer (Qty 1) CE
M8704 Fuse, 250V, 125 MA (for M7282) CE
(Replaces part M8652)
M6024 Transformer (for M7282) CE
77 22672 Relay, "Ice cube" (Qty 4) CE
78 M3443 Bushing, Adapter (Qty 2) CE
79 M2841 Fitting, Pressure Tap (Qty 2) CE
35 ; M7884 Probe, Flame Sensing (Qty 1) CE
(Before 7/15/99 or S.N. 071599GE066T)
Use if oven has not been burner retrofitted.
94 32206 Control, Hot Surface Ignition (Qty 1) CE
95 M6504 Ignitor, Hot Surface (Crossfire) (Qty 1) CE
JUNE 13, 2001 12 MT1828 E & G
