JUNE 13, 2001 6 MT1828 E & G
HOT SURFACE IGNITION
STANDARD FOR OVENS MANUFACTURED
BEFORE 07/15/99 OR S.N. 071599GE066T
SEE PICTURES ON PAGE 8
NOTE: IF YOU NEED TO ORDER THESE
PARTS OR YOUR OVEN STILL HAS THE
HOT SURFACE IGNITION, PLEASE
CONTACT THE BLODGETT SERVICE
DEPARTMENT WITH YOUR SERIAL
NUMBER!! 1-800-331-5842
Ref. Part
No. No. Description
36 M7885 Blower Motor, Combustion 60 HZ (Qty 1)
M6966 Gasket, Combustion Blower Motor (Qty 1)
M7883 Burner Assy. (Qty 1)
100 M5970 Complete Burner Assy. MT1828G
33 M7066 Orifice, Main Burner, Nat (MTD 34) (Qty 1)
33 R5059 Orifice, Main Burner, LP (MTD 49) (Qty 1)
NOTE: This orifice does not come pre-drilled. You
MUST specify the correct drill size, MTD 49.
34 M7815 Shroud, Flame Sensor (Qty 1)
35 ; M7884 Probe, Flame Sensing (Qty 1)
45 ; 30851 Control, Hot Surface Ignition (Qty 1)
46 ; M7886 Ignitor, Hot Surface (Crossfire) (Qty 1)
M6578 Plate Assy., Control MT1828G (Qty 1)
(Before 7/15/99 or S.N. 071599GE066T)
38 19086 Grommet, Rubber 5/8" (Qty 1)
40 ; M7028 Gas Valve, Nat (Qty 1)
40 ; M7154 Gas Valve, LP (Qty 1)
41 ; M0282 Gas Valve, Manual (Qty 1)
42 ; M0280 Tee, 3/4 x 3/4 x 1/4 (Qty 1)
43 M0281 Plug, Pipe 1/8 Black (Qty 1)
44 M6980 Manifold Assy. (Qty 1)
47 M7497 Pry Out Plug (for Burner) (Qty 1 )
M6958 Gasket, End Cap (Qty 1)
M9422 Pressure Switch
M9705 Polyurethane Tubing, used w/pressure
switch (Per Foot, Total 3 FT)
DIRECT SPARK IGNITION SYSTEM
STANDARD FOR OVENS MANUFACTURED
AFTER 07/15/99 OR S.N. 071599GE066T
SEE PICTURES ON PAGE 7
Ref. Part
No. No. Description
36 ; M7885 Blower Motor, Combustion 60 HZ (Qty 1)
M6966 Gasket, Combustion Blower Motor (Qty 1)
102 M10425 Orifice Assy, Main Burner, Nat
Replaces M10124
102 M10426 Orifice Assy, Main Burner, LP
Replaces M10125
M9705 Polyurethane Tubing, Per foot
NOTE: See Application below when ordering
(Total 2 ft. when used w/Burner Retrofit Kits)
(Total 3 ft. when used with Pressure Switch)
M9422 Pressure Switch
103 ; M9529 Ignition Control, Direct Spark
104 ; M9530 Burner Ignitor
; M9607 Probe, Temperature RTD 500 OHMS, 14"
105 ; M9517 Flame Sensor
106 ; M9871 Spark Wire only (Orange)
107 M9510 Burner, Complete LP & Nat
38 19086 Grommet, Rubber 5/8" (Qty 1)
40 ; M7028 Gas Valve, Nat & LP(Qty 1)
NOTE: This valve is for both Nat & LP only on
Direct Spark Ignition units made after
07/15/99
M9618 Harness, Gas Valve
41 ; M0282 Gas Valve, Manual (Qty 1)
42 M0280 Tee, 3/4 x 3/4 x 1/4 (Qty 1)
43 M0281 Plug, Pipe 1/8 Black (Qty 1)
