30
S Stte ep p 2 21 1
Place the heat distribution plates on
lower level of grill body assembly
directly above burners.
S Stte ep p 2 22 2
Place cooking grills on support ribs
directly above heat distribution
plates.
S Stte ep p 2 23 3
Place warming rack in slots above
cooking grills.
S Stte ep p 2 24 4
Remove igniter cap and insert battery
with positive end of battery toward
igniter cap. Ensure spring is in place
inside igniter cap. Replace igniter cap
and make sure the igniter is working
properly.
S Stte ep p 2 25 5
Slide small basket into slots located
on inside of left door.
Warming Rack
Cooking Grills
Heat Distribution
Plates
Igniter Cap
Battery
