FEATURES AND OPERATING CONTROLS (continued)
Brewer
Adjustable Legs
Connector
Hot Water Faucet
Nameplate
Control Panel
Start Brew Switch
Ready to Brew Indicator
Stop Brew Switch
Warmer Switch
Tank Heat Switch
Volume Selector Switch
Brew Chamber
Brew Chamber
Wire Rack
Satellite
Brew-Thru Lid
Handles
Serving Faucet
Sight Glass
Drip Tray (optional)
Allows brewer to be leveled. Also allow clearance for cleaning
underneath brewer.
Connects to satellite. Allows satellite heater to be energized.
Allows brewer to sense that a satellite is in place.
Hot water dispensed here.
Lists manufacturer, model and serial number.
Also lists voltage and wattage rating of brewer.
Press to start a brew.
Glows when water in tank is up to temperature.
Press to cancel a brew in progress.
Energizes satellite warmer.
Applies power to tank heater element. Glows when ON.
Allows selection of 1/2 gallon or 1 gallon brew (9102A); or,
1 gallon or 1-1/2 gallon brew (9104A).
Holds coffee grounds during brew cycle.
Holds paper filter and coffee grounds in proper position in brew
chamber.
Allows entry of brewed coffee and dilution water into satellite.
Minimizes splashing in the event satellite is tipped.
Allow the satellite to be safely carried.
Fresh coffee dispensed from satellite here.
Check the level of coffee remaining here.
Optional drip tray catches drips and spills from serving faucet.
Easily removed for cleaning.
