Product Descriptions
3
ready
B E L K I N
DC
input
1
2
3
4
WA
N
reset
Port Activity/Status Lights
Provide information about the network
Power Light
Indicates the power is on or off
RESET Button
Powers ON/OFF the router
without losing your settings.
LAN Ports
Connect your PCs to these ports
WAN Port
Connect your Cable or DSL
modem to this port
DC Power Jack
Connect the included power
supply to this jack
Front Panel
F5D5230-4
4-Port Cable/DSL Gateway Router
Rear Panel
WAN Link Status Light
Provides information about the connection to
the Cable or DSL modem
