—3—
SPECIFICATIONS
* Capacity and AFUE in accordance with U.S. Government DOE test procedures.
† Permissible voltage limits for proper furnace operation.
‡ Length shown is measured 1 way along wire path between unit and service panel for maximum 2% voltage drop.
** Time-delay fuse recommended.
*** Beckett AFG-F6 requires field supplied and replacement burner firing head.
†† For unit 036105
‡‡ For unit 060120
ICS—Isolated Combustion System
PSC—Permanent Split Capacitor
As Factory Shipped.
UNIT SIZE 036105 060120
SHIPPING WEIGHT (Lb) 235 260
RATINGS AND PERFORMANCE
Input Btuh 70,000 91,000 105,000 119,000 140,000 154,000
Output Capacity* Nonweatherized ICS 57,000 74,000 85,000 98,000 115,000 125,000
Nozzle—100 psig Pump Pressure 0.50—70W 0.65—70W 0.75—70B 0.85—70B 1.00—70W 1.10—70W
Firing Rate (GPH) 0.50 0.65 0.75 0.85 1.00 1.10
AFUE%* Nonweatherized ICS 81.4 81.4 81.4 80.6 80.6 80.6
Certified Temperature Rise Range ° F 55—85 55—85 55—85 55—85 55—85 55—85
Recommended Heating Blower Speed Med-Low Med-High High Med-Low Med-High High
Heating CFM @ 0.2-in. wc Static Pressure 840 1130 1425 1220 1555 1890
Cooling CFM @ 0.5-in. wc Static Pressure 1250 1250 1250 1865 1865 1865
ELECTRICAL
Unit Volts—Hertz—Phase 115—60—1
Operating Voltage Range Min—Max† 104—132
Maximum Unit Amps 12.2 15.7
Minimum Wire Size (AWG) 14
Maximum Wire Length (Ft)‡ 26
Maximum Fuse or Ckt Bkr Amps** 15 20
Transformer (24v) 40va
External Control Heating 40va
Power Available Cooling 30va
Air Conditioning Blower Relay Standard
BURNER AND CONTROLS
Burner Model (3450 RPM)*** Beckett AFG-F3 Beckett AFG-F3
Beckett
AFG-F6
Oil Pump Stages 1
Ignition Control Continuous
Heating Blower Control (Off Delay) Selectable 60, 90, 120, or 150 Sec
BLOWER DATA
Direct-Drive Motor HP (PSC) 1/3 3/4
Motor Full Load Amps 6.2 9.5
RPM (Nominal)—Speeds 1075—4
Blower Wheel Diameter X Width (In.) 10 X 8 12 X 10
Filter Size (In.)—Disposable (2) 12 X 20 X 1 (2) 16 X 20 X 1
FACTORY-AUTHORIZED AND LISTED, DEALER-INSTALLED OPTIONS
Electronic Air Cleaner AIRA
Mechanical Air Cleaner 902B
Air Cleaner Cabinet KEACA
Humidifier Model 912D, 912E, 913B, 913C, or 914A
Heat Recovery Ventilator Model VA3B, VB5B, or VC5B
Energy Recovery Ventilator Model VL3A
Thermostat—Non-Programmable For Use with 1-Speed Air Conditioner—TSTATBBNAC01-A
For Use with 2-Speed Air Conditioner—TSTATBBN2S01-A
For Use with 2-Speed Heat Pump—TSTATBBN2S01-A
Thermostat—Programmable For Use with 1-Speed Air Conditioner—TSTATBBPAC01-A
For Use with 2-Speed Air Conditioner—TSTATBBP2S01-A
For Use with 1-Speed Heat Pump—TSTATBBPDF01-A
For Use with 2-Speed Heat Pump—TSTATBBP2S01-A or TSTATBBPDF01-A
Zoning—2-Zone ZONEKIT2ZBDP, ZONEBB2KIT01
Zoning—4-Zone ZONEBB4KIT01
Zoning—8-Zone ZONEBB8KIT01
OIL NOZZLE KIT†† (QTY-50) 0.50 GPH For 70,000 Btuh — KLANZ0150050
OIL NOZZLE KIT†† (QTY-50) 0.65 GPH For 91,000 Btuh — KLANZ0250065
OIL NOZZLE KIT†† (QTY-50) 0.75 GPH For 105,000 Btuh — KLANZ0350075
OIL NOZZLE KIT‡‡ (QTY-50) 0.85 GPH For 120,000 Btuh — KLANZ0450085
OIL NOZZLE KIT‡‡ (QTY-50) 1.00 GPH For 140,000 Btuh — KLANZ0550100
OIL NOZZLE KIT‡‡(QTY-50) 1.10 GPH For 154,000 Btuh — KLANZ0650110
