46
LINESHARE PRO
Table 5-3. Protocol Tone Access Signal Options.
2 3 Protocol Tone Access Signal
The desired port selection (1-4)
4 The desired new Protocol Tone
Access Signal
* End programming sequence (3
beeps indicate correct entry)
(Optional entries for additional
changes)
* Save changes and exit
programming
The Protocol Tone Access Signal is
factory-preset to 0 6 1 9 *. Protocol
tone 0 will access Port 1, protocol
tone 6 will access Port 2, protocol
tone 1 will access Port 3, and
protocol tone 9 will access Port 4.
To change Protocol Tone 4 to access
a port, enter the programming
mode and press the following on
your tone phone:
Keypad # Protocol Tone Access Signal
0 1000 Hz
1 1100 Hz (typically fax CNG tone)
2 1200 Hz
3 1300 Hz
4 1400 Hz
5 1500 Hz
6 1600 Hz
9 2225 Hz (typically reverse modem tone)
