5.3.2 Unit Status Screen
Authority Level Required to Make Changes - Does not apply. No changes can be made from this
screen.
The Unit Status screen displays the following information about both air-conditioners.
Unit #1 Economizer On/Off
Unit #1 Compressor On/Off
Unit #1 Heater On/Off
Unit #1 Blower On/Off
Unit #1 Filter Clean/Dirty
Unit #1 Discharge Air Temperature Value DegF
Pressing the or key will scroll up or down respectively through the above screen
showing four lines at a time.
5.3.2.1 UNIT #1 ECONOMIZER
This display item will show "Off" if the unit #1 economizer output of the controller is not
energized. This display item will show "On" if the unit #1 economizer output of the controller is
energized.
5.3.2.2 UNIT #1 COMPRESSOR
This display item will show "Off" if the unit #1 compressor output of the controller is not
energized. This display item will show "On" if the unit #1 compressor output of the controller is
energized.
5.3.2.3 UNIT #1 HEATER
This display item will show "Off" if the unit #1 heater output of the controller is not energized.
This display item will show "On" if the unit #1 heater output of the controller is energized.
5.3.2.4 UNIT #1 BLOWER
This display item will show "Off" if the unit #1 blower output of the controller is not energized.
This display item will show "On" if the unit #1 blower output of the controller is energized.
UNIT STATUS
UNIT#1 ECON. OFF
UNIT#1 COMP. OFF
UNIT#1 HEAT ON
UNIT#1 BLOWER OFF
UNIT#1FILTER CLEAN
U#1 SUPPLY AIR 90.24
