Bottom casing – Liebherr HS 835 HD Litronic User Manual
Page 14
14
Cutting shoes
can be supplied with half-casing
connection or as a weld-on shoe.
General Remarks
D1/D2
S1
S2
d
B
Z
L - Working length (kg)
mm
Quantity of longitudinal bars
4 m
5 m
6 m
8 m
600/520
15
12
10
40
18
1660
2060
2450
3230
640/560
15
12
10
40
18
1780
2200
2620
3450
700/620
15
12
10
40
20
1960
2420
2880
3800
750/670
15
12
10
40
22
2110
2600
3100
4090
800/720
15
15
8
40
24
2430
3010
3600
4760
880/800
15
15
8
40
26
2680
3330
3970
5260
900/820
15
15
8
40
26
2750
3410
4070
5380
1000/920
15
15
8
40
30
3060
3800
4540
6010
1080/1000
15
15
8
40
32
3320
4110
4910
6510
1180/1100
15
15
8
40
36
3640
4510
5390
7130
1200/1120
15
15
8
40
36
3700
4590
5480
7260
1300/1220
15
15
8
40
40
4020
4990
5960
7890
1500/1400
15
15
18
50
45
5140
6325
7510
9880
1800/1700
20
20
8
50
55
7380
9156
10950
14520
2000/1880
20
20
18
60
60
8820
10900
12990
17110
2200/2080
20
20
18
60
66
9730
12010
14300
18860
2500/2380
20
20
18
60
76
11070
13670
16280
21490
2800/2680
20
25
8
60
86
14260
17740
21220
28170
2800/2640
20
25
27
80
86
16170
19970
23770
31380
2980/2840
20
25
27
80
90
17260
21310
25350
33450
3000/2840
20
25
27
80
90
17370
21440
25510
33660
3200/3040
20
25
27
80
98
21290
25650
30010
38810
∅ d
s1
s2
B
∅ D1
D2
S1
S2
Technical Data
HD
Bottom Casing
200
114
L
