CWM 5

Wall Mount Monitor

Product Summary

The B&W CWM 5 is the compact solution for in-wall speakers. It is completely versatile -

demanding little wall space - and is easy to accommodate in virtually any home or

commercial application.

Benefiting from B&W's in-house technology throughout, the CWM 5 makes few sonic

compromises. The sound quality easily exceeds most competitively priced conventional

loudspeakers.

B&W Loudspeakers Ltd reserves the right to amend details of the specifications without notice in line with technical developments. E & OE. All trademarks acknowledged.

www.bwspeakers.com

Drive Units

F requency Response

S e n s i t i v i t y

Nominal Impedance

Power Handling

1 x 125mm (5in) polypro p y l e n e

b a s s / m i d r a n g e

1 x 25mm (1in) polymer diaphragm -

tweeter

75Hz - 20kHz ± 3dB on re f e rence axis

87dB spl (2.83V 1m)

8 ohms

20 - 70W into 8 ohms on unclipped

p rogramme

D i m e n s i o n s

F i n i s h

Height: 227mm Width: 160mm

Min depth req: 75mm (3in) from wall

s u rface.

Semi-matt white suitable for

customising or pre-painting
