18 Form 6104 BCF10-R06
Replacement parts
Item Part Name Description Part Number
1 Timer Nozzle valve delay 21295U
2 Oil Valve Box mounted 21789U
3 Adjusting plate assembly CF10-2300 Kit 51213U
4 Knurled nut All models 3666
5 Fuel pump
B2TA-8245
H3PAN-C150H 21313U
21309U
6 Pedestal kit All models 51193
7 Fuel lines Specify length -
8 Damper spring All models 4339
9 Sight glass All models 31346
10 Rear cover door assembly
Cast aluminum door*
Stamped sheet-metal door* 5994U
5201301U
11 Control Specify -
12 Damper indicator All models 5985BK
13
Coupling Hole Plug
Coupling Access Door Use with threaded hole
Use with rectangular opening 32439U
16703GY
14 Head assembly CF1000 combustion 51203P
15 Electrode assembly All models 51212
16 Ignition leads
8-1/4” long
11-3/4” long
15-1/4” long
19-1/4” long
5990082
5990116
5990152
5990192
17 Nozzle line assembly Refer to Figure 2, Page 7
18 Air tube Refer to Figure 2, Page 7
19 Transformer 12,000 volt 51214
20 Coupling
B pump
H pump 21290
21308
21 Blower wheel CF1000 5.50” x 3.09” 21268U
22 Motor
120/208-230V single phase
208/230-460V three phase 21401U
21638U
Motor relay (not shown)
120V single phase
208V single phase
three phase 7273
7300
21719
Adjustable fl ange see Figure 13 on opposite page
* These doors are NOT interchangeable. Please specify what you are replacing.
