2 Attach the Document Support and
Paper Wire Extensions
Keep the packing materials for possible future transport. If you
do not pack the machine properly, it may void your warranty.
LF1748001
Brother
StartCard
For FAX-775, FAX-775Si, FAX-885MC
If you cannot solve a problem;
Refer to Frequently Asked Questions (FAQs) on Brother World Wide Web;
URL: http://www.brother.com
Call Brother Customer Service at;
USA: 1-800-284-4329
From within Canada: 1-877-BROTHER
From within Montreal: (514) 685-6464
THANK YOU !
CONGRATULATIONS ON PURCHASING A BROTHER MACHINE. WE ARE
SURE YOU WILL BE THRILLED WITH THE CONVENIENT WAY YOUR NEW FAX
PERFORMS SO MANY TASKS WITH DAZZLING RESULTS!
Follow these simple instructions in numerical order.
For more details, press Reports, 1 on your fax or see your Owner’s Manual.
The paper cassette can hold about 100 sheets of 20-lb. paper.
A. Open the paper cover.
B. Place up to 100 sheets of paper in the paper holder. Do not allow
the level of paper to pass maximum paper line on the paper guides.
C. Close the paper cover.
For more details, see “Connecting an External Telephone Answering Device”
in Chapter 2 of the Owner’s Manual.
9 For the USA only,
complete the
Warranty
Registration and
Test Sheet...
...and fax it to Brother
at 1-877-268-9575
Key once twice three times four times
A
D
G
P
J
M
T
W
B
E
H
K
N
Q
U
X C
F
R
I
L
O
V
Y
five times
2
3
4
5
6
S
8
Z A
D
G
7
9
J
M
T
2
3
4
5
6
7
8
9
7
Set Station ID
A. Press Menu/Set, 1, 2. 2.STATION ID
B. Enter your fax number (up to 20 digits),
and then press Menu/Set.
FAX:
C. Enter your telephone number (up to 20 digits), and
then press Menu/Set.
TEL:
D. Enter your name (up to 20 characters), and then
press Menu/Set.
NAME:
E. Press Stop/Exit.
8 Select a Receive
Mode
5 If you are sharing one Phone line
with an external telephone
answering device, connect it now 3
Load Paper
6
Set Date and Time
A. Press Menu/Set, 1, 1.
1.DATE/TIME
B. Enter the last two digits of the year, and then press
Menu/Set.
ENTER YEAR:XX
C. Enter two digits for the month, and then press
Menu/Set.
ENTER MONTH:XX
D. Enter two digits for the day, and then press
Menu/Set.
ENTER DAY:XX
E. Enter the time in 24-hour format and press Menu/Set.
ENTER TIME:XX:XX
F. Press Stop/Exit.
A. Insert the document support into the openings as shown in the illustration.
1
Packing List
Check that you have the following items:
Press Receive Mode until the correct mode for your setup is
displayed.
FAX ONLY The machine automatically
answers every call as a fax.
FAX/TEL For Receiving fax and voice calls
on one line.
TAD:ANSWER MACH.
(For FAX-775 and
FAX-775Si only)
An External TAD (telephone
answering device) answers every
call and stores voice messages
in memory, fax messages are
printed. An external telephone
operates as if it is in MANUAL
Mode when it is connected to
your Brother Machine.
MANUAL You control the phone line and
must answer every call yourself.
For more details, see chapter 5 of the owner’s manual.
B. Attach the paper wire extension.
Tap the stack of paper so the
edges are even.
Acceptable Paper
Size: Letter and Legal
Weight: 17 lb. – 24 lb.
Thickness: .0031 inches – .0039 inches
Telephone Line Cord
Telephone
Handset
Paper
Wire Extension
Starter
Print Cartridge
in the machine
(Up to 30 pages)
Document
Support
Owner’s Manual
Handset
Curled Cord
StartCard/
Quick Reference Card
Paper Guides
Maximum Paper Line
TAD
TAD
NO !
YES !
Document Support
Paper Wire
Extension
4
Install Phone Line and Power Cord
Handset Curled Cord
Telephone Line Cord
A. Connect the Handset.
B. Connect the telephone line.
C. Connect the power cord.
