Setting Up the Machine
7
8
While holding the paper tray in place, pull out
the paper support
until it clicks, and then
unfold the paper support flap
.
Note
Do not use the paper support flap
for Legal size
paper.
Note
You can use the photo bypass tray which is
located on the top of the paper tray to print on
photo 4
×
6 in. (10
×
15 cm) and photo L size
paper.
For details, see Loading photo paper in Chapter 2
of the User’s Guide.
4
Connecting the power cord
and telephone line
1
Connect the power cord.
2
Connect the telephone line cord. Connect one
end of the telephone line cord to the jack on the
machine marked LINE and the other end to a
modular wall jack.
Improper Setup
DO NOT connect the interface cable.
Connecting the interface cable is done during
the software installation process.
