Briggs & Stratton 233400 to 233499 - Manual (Page 8)

233400 to 233499
7584–8 Assemblies include all parts shown in frames. 68
8
212
206A
204
209
232
223
614
230
206
594
562
592
233
616
208 227
204 23849 Collar–Bell Crank
206 93422 Nut–Hex.
206A 21772 Nut–Governor
Adjusting
208 393613 Rod–Gov. Control
209 26764 Spring–Governor
212 26725 Link–Throttle
223 22814 Crank–Bell
(Furnished by Equip.
Manufacturer.)
Used on Type No(s).
0533, 0640.
227 291365 Lever–Governor
––––––– Note –––––
298399 Lever–Gov.
Used on Type No(s).
1111, 1133, 1136,
1164, 1170, 2520,
2528, 2561, 2580.
230 22826 Washer–Flat
232 260584 Spring–Link
233 93879 Spacer
562 92613 Bolt–Governor Lever
592 231082 Nut–Hex.
594 94905 Screw–Torx R Hex.
614 93306 Pin–Cotter
616 291364 Crank–Governor
K Included in Gasket Set–See Ref. No. 291728. D Included in Carburetor Kit–Part No. 395670.
REF. PART REF. PART REF. PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION
