Briggs & Stratton 233400 to 233499 - Manual (Page 13)

233400 to 233499
7584–13 Assemblies include all parts shown in frames. 68
13
59A
57
64
63
58
59
655
55
61
56
65
62
60
608
120
592A
55 394229 Housing–Rewind
Starter
56 392630 Pulley–Starter
(Includes 63” Rope)
57 490179 Spring–Rewind Starter
58 66884 Rope–Starter
(63” Long )
(For Use With Plastic
Pulley)
(If Longer Rope is
Required, Order 66894
and Cut to Required
Length)
59 490653 Insert–Grip
59A 230228 Pin–Starter Grip
60 490652 Grip–Starter Rope
61 68848 Bumper–Starter Pulley
62 93254 Screw–Hex.
63 260414 Spring–Ratchet
64 231118 Adapter–Spring
65 94694 Screw–Slotted Hex.
608 392677 Starter–Rewind
655 222598 Anchor–Spring
K Included in Gasket Set–See Ref. No. 291728. D Included in Carburetor Kit–Part No. 395670.
REF. PART REF. PART REF. PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION
