Nokia 7190 - Manual (Page 16)

[ 8 ]
Install the battery
1 Align the battery with the slots on
back of the phone.
2 Gently slide the battery toward the
antenna until you hear a click.
Charge the battery
1 Plug the lead from the charger into the circular jack
on the end of your phone.
2 Plug the AC adapter into a standard wall outlet.
The phone beeps and the battery bar on screen
starts to scroll from bottom to top.
Note: If the battery is empty, it will take a moment
for the bar on screen to begin scrolling.
Tip: You can use the phone while it’s charging.
3 When the battery bar stops scrolling, the battery
is fully charged.
Note: Charging time depends on the charger and battery. For example,
charging time for the BLS-2N battery with the ACP-7U charger is
about 2 hours.
4 Disconnect the charger from the phone and unplug it from the wall
outlet once the battery is fully charged.
