2-8 Communicator interface
Communicator interface conventions
The following figures illustrate certain communi-
cator interface conventions (Figure 2-11, 2-12).
(1) When a command appears dimmed, the com-
mand cannot be used.
(2) When a value appears on a dotted line with a
cursor, enter a new value manually via the
keyboard.
(3) When a pop-up box appears, choose an item
and press OK or Cancel.
When a setting with next to it is selected,
pressing Change toggles the value (e.g. on/off)
or opens a pop-up box (Figure 2-12).
When a setting with next to it is selected,
pressing Change opens a new settings view.
When you press a command with next to its
name, as in Records (Figure 2-10), only the
command set changes.
Figure 2-10: Communicator display
Figure 2-11: Example of commands
Figure 2-12: Example of a pop-up box
