User’s Manual 2-5
The Grand Tour
Back side
The following figure shows the computer back panel.
The back side of the computer
1. M ODEM J ACK
2. DC-IN 19V J ACK
3. LAN J ACK
4. U NIVERSAL S ERIAL B US (USB) P ORTS
1 4 2 3
Modem Jack In regions where an internal modem is installed
as standard equipment, this jack lets you use a
modular cable to connect the modem directly to a
telephone line.
DC-IN 19V Jack The DC IN jack is where you plug in the AC
adapter.
LAN Jack This jack lets you connect to a LAN. The adapter
has built-in support for Ethernet LAN
(10 megabits per second, 10BASE-T), Fast
Ethernet LAN (100 megabits per second,
100BASE-TX)
Universal Serial Bus
(USB) Ports
The Universal Serial Bus (USB 2.0 and 1.1
compatible) port enables USB-equipped devices
such as keyboards, mouse, hard drives,
scanners, and printers to be connected to the
computer.
