2-8 User’s Manual
A500/A500D series
Front with the display open
This section shows the computer with the display panel open. In order to
open the display, lift the display panel up and position it at a comfortable
viewing angle for you.
Figure 2-5 The front of the Touch Pad model with the display open
Memory module
slots The memory module slots are located here. The
memory module slots allow for the installation,
replacement and removal of additional memory
modules. Please refer to the
Additional memory
module section in Chapter 8, Optional Devices
for more information.
a. Power button
b .Stereo speakers
c. Front operational panel
d. Touchpad Enable/Disable button
e. Touchpad
f. Touchpad control buttons
*g. Fingerprint Sensor
h. System Indicators
i. Display hinge
j. Display screen
*k. Microphone
*l. Web Camera
*m. Web Camera LED
n. Wireless LAN antenna
o. LCD Sensor switch
n m l k
j
i
b
c
g
h
f
e
d
a
b
o
*Depending on the model you purchased.
