User’s Manual 2-1
Satellite P30 Series
Chapter 2
The Grand Tour
This chapter identifies the various components of your computer. Become
familiar with each component before you operate the computer.
Front with the display closed
The following figure shows the computer front with its display panel in the
closed position.
Front of the computer with display closed
Certain notebook chassis are designed to accommodate all possible
configurations for an entire product series. Your selected model may not
have all the features and specifications corresponding to all of the icons or
switches shown on the notebook chassis, unless you have selected all
those features.
DC-IN LED Power LED Battery LED Display Latch
DC-in LED The DC-IN LED indicates the computer is
connected to the AC adapter and it is plugged
into an AC power source.
