Controls and displays 03
24
En
LCD touch screen
10 (AUDIO)
Press to select the audio channel or language.
(SUBTITLE)
Press to select a subtitle display.
(ANGLE)
Press to change the camera angle during BD-ROM or
DVD-Video movie multi-angle scene playback.
11 Playback controls

Press to start or resume playback.

Press to stop playback (you can resume playback by
pressing
).

Press to pause playback; press again to restart.
, 
Press to jump to the start of the previous/next
chapter/track.
, 
Press to start reverse/forward scanning.
/ , / 
Use for slow motion and step frame.
12 HMG
Press to display/hide the Home Media Gallery screen.
13 MENU
Press to display the BD-ROM or DVD-Video menus.
14 2nd AUDIO
When playing a BD-ROM on which secondary audio is
recorded, press to switch to the secondary audio.
15 2nd VIDEO
When playing a BD-ROM on which secondary video
(Picture-in-Picture) is recorded, press to switch to the
secondary video.
16 OPEN/CLOSE
Press to open and close the disc tray.
17 Number buttons
Use these to select and play the title/chapter/track
you want to watch or listen to and to select items
from menus.
ENTER
Press to execute the selected item or enter a setting
that has been changed, etc.
CLEAR
Press to clear the numeric number, etc.
18 PLAY MODE
Press to display/hide the Play Mode screen.
19 VIDEO ADJ
Press to display/hide the Video Adjust menu.
20 FL DIMMER
Press to switch the brightness of the player’s front panel
display. The
FL OFF indicator lights when Off is selected.
21 VIDEO SEL
Press to switch the player’s terminal from which the
video signals are output. Use to switch between digital
output (HDMI output) and analog output (Component
Video output, S-Video output or Video output)
(the
signals are only output from the selected video
output terminal).
22 RESOLUTION /
Use these to switch the output video resolution from the
player’s
HDMI OUT or COMPONENT VIDEO output
terminals.
