Pioneer BCS-222 - Manual (Page 74)

Appendix 74
En
A
ppendix
10
Amplifier for BCS-424/BCS-222
Power output (RMS) THD 30 %
Total
1100 W
Front 170 W × 2 (4 Ω)
Center 250 W (3 Ω)
Rear 170 W × 2 (4 Ω)
Sub-Woofer 250 W (3 Ω)
Amplifier for BCS-FS121
Power output (RMS) THD 30 %
Total
550 W
Front 170 W × 2 (4 Ω)
Sub-Woofer 250 W (3 Ω)
System
Laser
Semiconductor laser
Signal system Standard PAL/NTSC colour TV system
LAN port Ethernet jack x 1, 10BASE-T / 100BASE-TX
Bus Power Supply (USB) DC 5 V 500 mA
Speakers for BCS-424
S-BD422
• Front (Left/Right)
Type 2 Way
Net Dimensions
(W x H x D)
250 mm x 1110 mm x 250 mm
Impedance Rated 4 Ω Net Weight 3.5 kg
• Surround speaker (Left/ Right)
Type 1 Way
Net Dimensions
(W x H x D)
250 mm x 1110 mm x 250 mm
Impedance Rated 4 Ω Net Weight 3.4 kg
• Center speaker
Type 1 Way
Net Dimensions
(W x H x D)
230 mm x 80 mm x 90 mm
Impedance Rated 3 Ω Net Weight 0.7 kg
• Subwoofer
Type 1 Way
Net Dimensions
(W x H x D)
200 mm x 340 mm x 270 mm
Impedance Rated 3 Ω Net Weight 3.4 kg
