Page 15: Dimensions diagram, Unit: mm (inch)
15
En
English
80
(3-5/32)
169.5
(6-11/16)
40 (1-9/16)
39
(1-17/32)
115
(4-17/32)
1040 (40-15/16)
237 (9-11/32)*
1
238 (9-3/8)*
2
550 (21-21/32)*
1
552 (21-23/32)*
2
679 (26-23/32)
42 inch display model
Unit: mm (inch)
Dimensions Diagram
Published by Pioneer Corporation.
Copyright © 2007 Pioneer Corporation.
All rights reserved.
Without speakers (50 inch display model)
Unit: mm (inch)
70
(2-3/4)
213.5
(8-13/32)
80
(3-5/32)
1224 (48-3/16)*
3
1232 (48-1/2)*
4
717 (28-7/32)*
3
722 (28-7/16)*
4
68 (2-11/16)*
3
65.5 (2-19/32)*
4
300 (11-13/16)*
1
301 (11-27/32)*
2
115 (4-17/32)*
3
119 (4-11/16)*
4
550 (21-21/32)*
1
552 (21-23/32)*
2
*
1
PDK-TS27
*
2
PDK-TS27A
*
1
PDK-TS29
*
3
50 inch XGA model
*
2
PDK-TS29A
*
4
50 inch FHD model
