Specifications
General
Rated power source ............... 14.4 V DC
(allowable voltage range:
12.0 V to 14.4 V DC)
Earthing system ....................... Negative type
Maximum current consumption
........................................... 10.0 A
Dimensions (W × H × D):
AVIC-F20BT
DIN
Chassis ..................... 188 mm × 118 mm ×
157 mm
Nose ........................... 170 mm × 96 mm × 25 mm
D
Chassis ..................... 178 mm × 100 mm ×
165 mm
Nose ........................... 170 mm × 96 mm × 17 mm
AVIC-F920BT
DIN
Chassis ..................... 188 mm × 118 mm ×
157 mm
Nose ........................... 170 mm × 96 mm × 20 mm
D
Chassis ..................... 178 mm × 100 mm ×
165 mm
Nose ........................... 170 mm × 96 mm × 11 mm
AVIC-F9210BT
D
Chassis ..................... 178 mm × 100 mm ×
155 mm
Nose ........................... 220 mm × 133 mm ×
21 mm
AVIC-F9220BT
D
Chassis ..................... 178 mm × 100 mm ×
155 mm
Nose ........................... 227 mm × 120 mm ×
22 mm
Weight:
AVIC-F20BT ....................... 2.97 kg
AVIC-F920BT .................... 2.51 kg
AVIC-F9210BT .................. 2.24 kg
AVIC-F9220BT .................. 2.25 kg
NAND flash memory ............. 4 GB
Navigation
GPS Receiver:
System ................................ L1, C/Acode GPS
SPS (Standard Positioning
Service)
Reception system .......... 30-channel multi-channel
reception system
Reception frequency .... 1 575.42 MHz
Sensitivity ..........................
–140 dBm (typ)
Position update frequency
........................................... Approx. once per second
GPS aerial:
Aerial ................................... Micro strip flat aerial/right-
handed helical polarisation
Aerial cable ...................... 3.55 m
Dimensions (W × H × D)
........................................... 33 mm × 15 mm × 36 mm
Weight ................................ 73.7 g
Display
Screen size/aspect ratio:
AVIC-F20BT ....................... 7 inch wide/16:9
AVIC-F920BT .................... 6.1 inch wide/16:9
AVIC-F9210BT .................. 6.1 inch wide/16:9
AVIC-F9220BT .................. 6.1 inch wide/16:9
Effective display area:
AVIC-F20BT ....................... 159 mm × 84 mm
AVIC-F920BT .................... 138 mm × 73 mm
AVIC-F9210BT .................. 138 mm × 73 mm
AVIC-F9220BT .................. 138 mm × 73 mm
Pixels ............................................. 384 000 (800 × 480)
Display method ........................ TFT Active matrix driving
Backlight ..................................... LED
Colour system ........................... PAL/NTSC compatible
Tolerable temperature range:
Power on ............................
–10 °C to +60 °C
Power off ............................ –20 °C to +80 °C
Angle adjustment
AVIC-F20BT ....................... 0° to 22°
AVIC-F920BT .................... 0°
AVIC-F9210BT .................. 0°
AVIC-F9220BT .................. 0°
Audio
Maximum power output ....... 50 W × 4
50 W × 2 ch/4
W + 70 W ×
1 ch/2
W (for subwoofer)
Continuous power output ... 22 W × 4 (50 Hz to 15 kHz,
5 %THD, 4
W LOAD, Both
Channels Driven)
Load impedance ...................... 4 W (4 W to 8 W [2 W for 1 ch]
allowable)
Preout output level (max):
AVIC-F20BT ....................... 4.0 V
AVIC-F920BT .................... 2.2 V
AVIC-F9210BT .................. 2.2 V
AVIC-F9220BT .................. 2.2 V
Preout impedance:
AVIC-F20BT ....................... 100 ohm
AVIC-F920BT .................... 1 kohm
AVIC-F9210BT .................. 1 kohm
