Part names and functions 02
8
En
10 Tuner control buttons
SHIFT
Press to access the ‘blue’ commands (above the
buttons) on the remote. These buttons are marked with
an asterisk (*) in this section.
RDS ASPM
Use to search for RDS Auto station program memory
(page 29).
RDS PTY
Use to search for RDS program types (page 29).
RDS DISPLAY
Press to change the RDS display for information mode
(page 30).
11 OPEN/CLOSE
Use to open or close the disc tray (page 20).
12 DVD Receiver control buttons
CLOCK/TIMER
Use for setting the clock, as well as for setting and
checking the timers (page 15).
SLEEP
See Using the sleep timer on page 17.
13 Sound control buttons
Adjust the sound quality (page 16).
14 DISPLAY
Press to change the display for DVD-Video, Video CD, CD or
MP3.
Ex.: DVD-Video DISPLAY
15 RPT/RDM
Press to change the repeat play or randomize order play
setting from a DVD-Video, Video CD, CD or iPod (page 21).
16 Volume control buttons
Use to set the listening volume (page 15).
17 DIMMER
Dims or brightens the display. The brightness can be
controlled in four steps (page 15).
Note
• This unit does not use the OPTION buttons.
Speaker system
1 Tweeter
2 Woofer
3 Bass Reflex Duct
4 Speaker Terminals
Important
• Speaker grille can be removed.
• Make sure nothing comes into contact with the speaker
diaphragms when you remove the speaker grilles.
• Both speakers can be used on either the right or the left
side.
Detatching and replacing the front
grille
The front grille of this speaker system is removable. Proceed
as follows:
1 Grab the bottom of the grille, and gently
pull it toward you to remove the bottom
portion.
2 Next, grab the top part of the grille and
gently pull it toward you to remove the top
portion.
To install the grille, align the projections on the speaker with
the receptacles on the top and at the base of the grille and
push them into place.
Play Playback status
Time display
Subtitle Language
Audio Language
Audio format
DVD-Video
Current / Total
1 Chinese - - 1
Audio Dolby Digital 2 / 0 CH Subtitle Angle
1/4 Title
Elapsed Remain Total
5:34 35:56 41:30

Play 
PAUSE 
Slow Backward 
Slow Forward 
Fast Backward 
Fast Forward 
3
2
1
4
