About how digital audio formats are output
Note
• Depending on the disc, the number of channels may differ.
• Depending on the connected HDMI device, the HDMI output audio and number of channels may differ.
• The HDMI output audio and number of channels may differ when Resolution is set to 480I or 480P, as well as
when set to Auto if the connected device only supports 480i/480p.
• Three types of audio are recorded on BD video discs.
– Primary audio: The main sound.
– Secondary audio: Additional sound added supplementarily, such as comments by directors, actors, etc.
– Interactive audio: Sounds such as clicks heard when operations are performed. The interactive audio differs
from disc to disc.
Setting Bitstream PCM Re-encode
Method of
conversion
Only the primary audio (the
main sound for movies, etc.) is
output. The secondary audio
and interactive audio are not
output. The primary audio, secondary
audio and interactive audio are
converted into PCM audio and
output simultaneously. The primary audio, secondary
audio and interactive audio are
converted into PCM audio then
converted again into Dolby
Digital audio or DTS audio and
output simultaneously. 1
1. If there is no secondary audio or interactive audio, depending on the disc the signals may be output without being re-encoded.
Output
terminal(s)
Audio type
HDMI OUT
terminal
DIGITAL OUT
terminal
HDMI OUT
terminal
DIGITAL OUT
terminal
HDMI OUT
terminal
DIGITAL OUT
terminal
AUDIO
OUTPUT
terminal 2
2. BDP-150 only.
Dolby Digital Dolby Digital Dolby Digital PCM 5.1ch
PCM 2 ch 3
3. For multi-channel audio, the sound is converted into 2-channel audio for output.
Dolby Digital Dolby Digital
2 ch 3
Dolby Digital
Plus Dolby Digital
Plus
Dolby Digital PCM 7.1ch
Dolby TrueHD Dolby TrueHD Dolby Digital PCM 7.1ch
DTS Digital
Surround DTS Digital
Surround
DTS Digital
Surround
PCM 5.1ch
DTS 5.1ch DTS 5.1ch
DTS-HD High
Resolution Audio
DTS-HD High
Resolution
Audio
DTS ES 6.1 ch PCM 7.1ch
DTS-HD
Master Audio DTS-HD
Master Audio
DTS ES 6.1 ch PCM 7.1ch
PCM PCM 7.1ch PCM 2 ch 3 PCM 7.1ch Dolby Digital Dolby Digital
MPEG-2 AAC 4
4. Only for ASEAN and Taiwan models.
MPEG-2 AAC MPEG-2 AAC PCM 5.1ch MPEG-2 AAC MPEG-2 AAC
SACD (DSD) DSD 5.1ch 5
5. When Resolution is set to 480I or 480P, or even when it is set to Auto, if the connected device does not support 480i/480p, the DSD audio
of SACDs is output in two channels, front left and front right (page 41).
PCM 2 ch 6
6. When HDMI Audio Out is set to Bitstream, the sound is not output (page 42).
PCM 5.1ch PCM 2 ch 6 PCM 5.1ch PCM 2 ch 6 2 ch 6
DVD-Audio 7
7. BDP-450 only.
PCM 5.1ch 8
8. When the connected device has two channels (front left and right), with DVD Audio discs prohibiting downmixing, the multi-channel audio
signals are output as two channels (front left and right).
PCM 2 ch 3, 9
9. Digital sound is not output for discs on which downmixing is prohibited.
PCM 5.1ch 8 PCM 2 ch 3, 9 PCM 5.1ch 8 PCM 2 ch 3, 9 2 ch
