3
En
L
R
AM
LOOP
FM
UNBAL
75Ω
ANTENNA
SPEAKERS
LAN (10/100)
(OUTPUT 5V
0.1 A MAX)
PRE OUT
OUT
IN
L
R
AM
LOOP
FM
UNBAL
75Ω
ANTENNA
SPEAKERS
WLAN ANTENNA
LINE
VIDEO
SUBWOOFER
L
R
ADAPTER PORT
LAN (10/100)
WAN
3
2
1
LAN
X-HM81
XC-HM81
WLAN ANTENNA
1
2
WLAN ANTENNA
3
Video cable
(commercially available)
TV
To video input
socket
To AC outlet
Connect Bluetooth
®
wireless
technology ADAPTER AS-BT100 or
AS-BT200 (sold separately)
Power cord
Supplied WLAN antenna
The Bluetooth
®
word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by PIONEER CORPORATION is under license.
Other trademarks and trade names are those of their respective owners.
Connecting the speakers
CAUTION
•These speaker terminals carry
HAZARDOUS LIVE voltage. To prevent
the risk of electric shock when connecting
or disconnecting the speaker cables,
disconnect the power cord before touching
any uninsulated parts.
•Make sure that all the bare speaker wire
is twisted together and inserted fully into
the speaker terminal. If any of the bare
speaker wire touches the back panel it
may cause the power to cut off as a safety
measure.
Be sure to complete all connections before connecting this receiver to the AC power
source.
Connecting a TV and playback component
L
R
AM
LOOP
FM
UNBAL
75Ω
A
SPEAKERS
1
2
3
Right speaker
Left speaker
Make sure you connect the speaker on the
right to the right (R) terminal and the speaker
on the left to the left (L) terminal. Also make
sure the positive and negative (+/–) terminals
on the receiver match those on the speakers.
You can use speakers with a nominal
impedance between 4
Ω and 16 Ω.
10 mm
1. If not using the provided speaker wire,
twist exposed wire strands together.
2. Loosen terminal and insert exposed
wire.
3. Tighten terminal.
Connecting antennas
Connect your iPod/iPhone/iPad or USB
device to the USB/iPod/iPhone/iPad terminal
on the front panel.
USB mass
storage device
USB cable provided with iPod/iPhone/iPad units, or
a commercially available USB cable to support iPod/
iPhone/iPad (for iPod connection)
STANDBY/ON
INPUT
PHONES
AUDIO IN
USB
iPod/iPhone/iPad
NET STANDBY/
POWER
CHARGE
TIMER
VOLUME
iPod/iPhone/
iPad
Connecting your iPod/iPhone/iPad
or USB device
Connecting your iPod/iPhone to
the docking station
Dock connector
iPod/iPhone (bottom)
iPod/iPhone connector
iPod/iPhone
1. Open the dock cover by pulling up.
2. If you have the Universal dock adapter, attach
it to iPod/iPhone connector port.
3. Connect your iPod/iPhone.
FM wire
antenna
Connect the supplied WLAN antenna as
show above.
Connect the FM wire antenna and the AM
loop antenna as shown below.
AM loop
antenna
Modem
To LAN
port
Internet
Router
LAN cable
(commercially available)
PC
Red tube
X-HM81 and X-HM71
provided speaker wire
