Service Mode
9-10 R5976336 BARCOSLM R6 Executive 06092001
I2C DIAGNOSIS
D CA
DECODER 12H # # #
MOTOR DRIVER 1AH # # #
LIGHT SENSOR 1CH # # #
LAMP DRIVER 20H # # #
POWER SUPPLY 30H # # #
FORMATTER 34H # # #
PMP 4AH # # #
INPUT SELECTOR 72H # # #
INPUT SELECTOR 98H # # #
INPUT SELECTOR 9AH # # #
LAMP MODULE A0H # # #
Scroll with é or ê
to return.
menu 2
I2C Diagnosis
How to select ?
1 Push the cursor key é or ê to highlight 'I2C' (menu 1).
2 Press ENTER to select.
The I2C Diagnosis overview will be displayed.
If the indication behind the hex code is green, everything is ok.
If the indication is red, something is wrong with that indicated address.
Select with é or ê
then
to return.
menu 1
DIAGNOSIS
I2C
FORMATTER
Formatter
How to select the overview ?
1 Push the cursor key é or ê to highlight 'Formatter' (menu 1).
2 Press ENTER to select.
An overview of the working of the formatter will be displayed (menu 2).
Select with é or ê
then
to return.
menu 1
DIAGNOSIS
I2C
FORMATTER
FORMATTER
I2C (34H) OK
CONFIGURATION OK
INITIALISATION OK
SELF TEST OK
RED DISPLAY OK
GREEN DISPLAY OK
BLUE DISPLAY OK
to return.
menu 2
