8-3
Installation Mode
R5976336 BARCOSLM R6 Executive 06092001
Select with é or ê
to toggle
to return.
800 PERIPHERAL
menu 2
OUTPUT MODULE [STANDARD]
INFRARED [ PPM ]
Defining the Infrared Communication protocol
When a peripheral is connected to the 'Comm Port', the communication can be in PPM or RC5.
The type of communication can be set to :
- PPM
- RC5
To define the communication :
1 Push the cursor key é or ê to highlight '800 Peripheral' (menu 1).
2 Press ENTER to select.
3 Push the cursor key é or ê to highlight 'Infrared'.
4 Press ENTER to toggle between [PPM] or [RC5].
Select with é or ê
then
to return.
INSTALLATION
INPUT SLOTS
800 PERIPHERAL
CONVERGENCE
CONFIGURATION
OSD COLOR
INTERNAL PATTERNS
NO SIGNAL
LENS
QUICK ACCESS KEYS
MENU POSITION [DEFAULT]
menu 1
Convergence
What can be done ?
The convergence of the displayed image can be adjusted only by a qualified service technician.
How to start up ?
1 Push the cursor key é or ê to highlight 'Convergence' (menu 1).
2 Press ENTER to select.
When Convergence is selected in the Installation Mode selection menu, the following warning will be displayed :
Convergence is reserved to qualified service personnel.
If you are not qualified, press EXIT to cancel the Convergence selection.
WARNING
CONVERGENCE
is reserved to
qualified
service personnel
to accept
to return.
menu 2
Select with é or ê
then
to return.
menu 1
INSTALLATION
INPUT SLOTS
800 PERIPHERAL
CONVERGENCE
CONFIGURATION
OSD COLOR
INTERNAL PATTERNS
NO SIGNAL
LENS
QUICK ACCESS KEYS
MENU POSITION [DEFAULT]
