7
Flash s
h
ooting
70
EN
In addition to the camera’s built-in flash capabilities, you can use any of the external flash units
specified for use with this camera. This enables you to take advantage of a wider variety of
flash shooting techniques to suit different shooting conditions.
The external flashes communicate with the camera, allowing you to control the camera’s flash
modes with various available flash control modes, such as TTL-AUTO and Super FP flash. An
external flash unit specified for use with this camera can be mounted on the camera by
attaching it to the camera’s hot shoe.
Refer to the external flash’s manual as well.
Functions available with external flash units
* The focal length of the lens that can be used (Calculated based on 35 mm film camera)
x
Notes
• The FL-40 optional flash cannot be used.
Using the external electronic flash
Be sure to attach the flash to the camera before turning on the flash’s power.
1
Remove the hot shoe cover by sliding it in the
direction indicated by the arrow in the
illustration.
• Keep the shoe cover in a safe place to avoid losing it.
You can attach the shoe cover to the back of the
eyepiece cover, which is attached to the strap. Put
the shoe cover back on the camera after removing
the external flash.
2
Attach the electronic flash to the hot shoe
on the camera.
• If the lock pin is protruding, turn the shoe lock
ring as far as it will go in the direction opposite
to LOCK. This will pull the lock pin back inside.
3
Turn on the flash.
• When the charge lamp on the flash lights up, charging is
complete.
• The flash will be synchronized with the camera at a speed
of 1/180 sec. or less.
4
Select a flash mode.
5
Select the flash control mode.
• TTL-AUTO is recommended for normal use.
6
Press the shutter button halfway.
• Shooting information such as ISO sensitivity, aperture
value, and shutter speed is communicated between the
camera and flash.
7
Press the shutter button all the way.
External flash shooting
Optional flash FL-50R FL-50 FL-36R FL-36 FL-20 RF-11 TF-22
Flash control mode
TTL-AUTO, AUTO, MANUAL,
FP TTL AUTO, FP MANUAL
TTL-AUTO,
AUTO, MANUAL
TTL-AUTO,
MANUAL
GN (Guide number)
(ISO100) GN50 (85 mm * )
GN28 (24 mm * )
GN36 (85 mm * )
GN20 (24 mm * )
GN20 (35 mm * ) GN11 GN22
RC mode 9 k 9 k k k k
Hot shoe cover
Lock pin Lock ring
