CAMERA DIAGRAM
DC-IN jack
USB connector
Flash
Self-timer lamp
Lens
Arrow pad
(
acbd)
Tripod socket
Card cover
Card access lamp
Erase button (
S)
Playback button ($)
Monitor
Strap eyelet
Mode dial
Shutter button
Shooting button (#)
Battery compartment cover
Mode dial
POWER switch
Zoom button
(W/T, GU)
