DM320

Floor-standing loudspeaker system

Product Summary

If greater efficiency and bass extension are called for then the DM320 with its larger

enclosure and the 3-way system comes into its own.

Equipped with two 8in bass units in a closed box configuration and the acclaimed magnetic

fluid-cooled, light-alloy domed tweeter offers an extended low frequency range with higher

sensitivity.

Technical highlights

The use of a aluminium domed tweeter immediately distinguishes the two models. The specially

created 26mm (1in) tweeter enables high power handling to cope with the heavier usage

imposed on modern hi-fi systems. Frequencies in excess of 20kHz are within its range.

Subtle changes to the cabinet such as the tweeter plate, and bevelled front edges of the cabinet,

help produce a dramatically more even frequency response. The B&W tradition of attention to

detail manifests itself other features, such as the reinforced low-frequency driven diaphragm, the

rigid die-cast chassis, and the provision for bi-wiring or bi-amplification.

B&W Loudspeakers Ltd reserves the right to amend details of the specifications without notice in line with technical developments. E & OE. All trademarks acknowledged.

www.bwspeakers.com

Description

Drive Units

3-way 3rd-order, closed box digital

monitor system with bi-wiring/bi-

amplification facility

1 x 26mm high-frequency with metal

dome

2 x 200mm bass/midrange with rigid

die-cast chassis, reinforced

polypropylene and 31mm high

temperature voice coil on Kapton®

former

Frequency Response

Sensitivity

Nominal Impedance

Power Handling

Dimensions

Finish

60Hz – 20kHz ± 2dB on reference

axis

91dB spl(2.83V 1m)

8 ohms

25W – 100W into 8 ohms on

unclipped programme

Height: 656mm Width: 262mm

Depth: 280mm

Anthracite, black ash or walnut vinyl
