. 18 HSM
inStallation
/
operation
/
Service Manual
S E R V I C E
MODEL > HSM-38/3S HSM-48/5S
ITEM DESCRIPTION PART NO. QTY PART NO. QTY
1 PANEL, COVER, LOWER BACK 1003444 1 1002785 1
2 UPPER BACK COVER PANEL W/ VENTS 1003443 1 1002786 1
3 BOTTOM END GLASS CLIP HOLDER 1002820 2 1002820 2
4 TOP END GLASS CLIP HOLDER 1002839 2 1002839 2
5 FRONT SLIDE COVER PANEL 1003903 1 1010815 1
6 FRONT SLIDING PANEL (NOT SHOWN) 1003904 1
—
1
7 FORMICA SIDE ATTACHMENT BRACKET 1003955 2 1003901 2
8 SHELF FRONT COVER 1005626 2 1005420 4
9 RT SIDE END GLASS GL-26273 1 GL-25945 1
10 LF SIDE END GLASS GL-26272 1 GL-25951 1
11 1.000" THICK YELLOW BOARD INSULATION IN-22265 22 FT IN-22265 16 FT
12 KNOB, STAINLESS, SLIDING PANEL KN-26379 1 KN-26379 1
13 RATING TAG LABEL LA-26348 2 LA-26348 2
14
LAMPS, FLORESCENTS, SOFT WHITE 208-240V
230V
380-415V
LP-34156
LP-33822
LP-33822
3
LP-33822
LP-33822
LP-33822
10
15 FORMICA SIDE PANEL PE-26274 2 PE-26068 2
16 SCREW, M2.9X9, 5MM, PAN SC-22305 4 SC-22305 4
17 8-32 X 3/8" TRUSS HEAD SC-22378 12 SC-22378 6
18 M6 X 45 FLAT HEAD SC-24978 12 SC-24019 12
19 8-32 X 1/4" PHIL SCREW SC-2459 64 SC-2459 45
EXTERIOR PARTS LIST C
D A N G E R
ENSURE POWER SOURCE
MATCHES VOLTAGE STAMPED
ON APPLIANCE NAMEPLATE.
D A N G E R
LOCK-OUT OR POST
BREAKER PANEL UNTIL
SERVICE WORK HAS
BEEN COMPLETED.
