Exterior parts list b – Alto-Shaam HSM-48/5S User Manual
Page 18
pg
. 16
HSM
inStallation
/
operation
/
Service
Manual
S E R V I C E
MODEL >
HSM-38/3S
HSM-48/5S
ITEM
DESCRIPTION
PART NO.
QTY
PART NO.
QTY
1
RT LOWER SIDE PANEL
StainleSS
Steel
black
burgundy
1005706
1005707
1003447
1
1005473
1004668
1002780
1
2
LF LOWER SIDE PANEL
StainleSS
Steel
black
burgundy
1005708
1005709
1003448
1
1005474
1004669
1002781
1
3
FRONT COVER PANEL
StainleSS
Steel
black
burgundy
1005710
1005711
1003441
1
1010928
1010927
1010926
1
4
BASE GLASS COVER PANEL
1003445
1
1002832
1
5
BUMPER RIGID BASE
1003454
1
1003452
1
6
SHELF RT END SUPPORT BRACKET
1005421
2
1005421
4
7
SHELF LF END SUPPORT BRACKET
1005422
2
1005422
4
8
SHIM, SHELF
1006253
4
1006253
8
9
CANOPY SPOT
StainleSS
Steel
black
burgundy
5004558
5004559
5002540
1
5004423
5003639
5002003
1
10
SHELF ASSEMBLY W/ HEATED GLASS
5004498
2
5004409
4
11
BUMPER TOP, BLACK
BM-26261
3 FT
BM-26261
4 FT
12
CLAMP ASSEMBLY
CM-26878
1
CM-26879
1
13
1100W HEATED GLASS
GL-26512
1
GL-25860
1
14
FRONT CURVED GLASS
GL-26275
1
GL-26081
1
15
10-32 THREADED INSERT
HG-22672
16
HG-22672
32
16
RECEPTACLE
RP-34160
6
RP-34160
12
17
SCREW,8-32 X 1, NC PHILLIPS PAN
SC-2069
5
SC-2069
3
18
10-32 X 3/4 PAN HD
SC-2071
16
SC-2071
32
19
8-32 X 1/4" PHIL SCREW
SC-2459
64
SC-2459
14
20
SCREW,10-32 X1/2,NF PHIL TRUSS M/S,18-8 SS
SC-2661
12
SC-2661
36
EXTERIOR PARTS LIST
B
D A N G E R
ENSURE POWER SOURCE
MATCHES VOLTAGE STAMPED
ON APPLIANCE NAMEPLATE.
D A N G E R
LOCK-OUT OR POST
BREAKER PANEL UNTIL
SERVICE WORK HAS
BEEN COMPLETED.
