Chapter 4 Remote Interface Reference
Simplified Programming Overview
80
Power Supply Programming Ranges
The
SOURce
subsystem requires parameters for programming values. The
available programming value for a parameter varies according to the desired
output range of the power supply. The following table lists the programming
values available and MINimum, MAXimum, DEFault and reset values of the
Agilient E3632A power supply.
Refer to this table to identify programming values when programming the power
supply.
Table 4-1 . Agilent E3632A Programming Ranges
0 - 15V/7A Range 0 - 30V/4A Range
Voltage Programming Range 0 V to 15.45V 0 V to 30.9 V
MAX Value 15.45 V 30.9 V
MIN Value 0 V 0 V
DEFault Value 0 V 0 V
*RST Value 0 V
Current Programming Range 0 A to 7.21 A 0 A to 4.12 A
MAX Value 7.21 A 4.12 A
MIN Value 0 A 0 A
DEFault Value 7 A 4 A
*RST 7 A
